The presented configuration represents the most popular choice among customers – a proven and efficient option for serial production.

Main Features:

• Front supports: 2 pcs on linear guides, ensuring stability during bending operations.

• Back gauge adjustment (X-axis): automatic

• Ram adjustment (Y1, Y2 axes): automatic

• Finger height adjustment (R-axis): manual (option* servo drive)

• Double-sided punch clamping: quick AMADA-type mounting system enabling rapid tool changes.

Available configurations are customised to production requirements and the type of processed workpieces – the machine specification is determined individually according to application and technological demands.

Technical parameters

Manual or automatic adjustment of back gauge height. The R-axis facilitates bending of larger radii, e.g. with step bending system.

Although the step bending process may seem complicated, CORMAK machines and software are so advanced that they can perform many calculations automatically, relieving the operator of most tasks.

Automatic crowning compensation

Ensures a consistent bending angle along the entire working length – (option*)

Manual crowning compensation (option*)

Ensures the same bending angle across the whole working length – (option*)

High-quality components:

• Electrical components by Schneider / Delta / Eaton

Control and functionality:

CR-41 CNC

• Equipped with a 10-inch touchscreen on a movable arm for full working range access.
• Programmability: stores up to 2000 programs with 30 steps each.
• Ergonomic Interface: intuitive English menu simplifies operation.

The machine combines advanced technology with ease of use, making it ideal for both precision manual tasks and efficient serial production. High-quality components and advanced safety features ensure reliability and operator safety.

Safety

Laser safety system

Only in our machines as standard — a top-class laser safety system protecting the operator and doubling the bending process speed.

No compromises on safety! Highest-class hydraulic connections and safety valves designed in Poland.

Beware of pseudo-safety systems like light curtains or gates — they do not meet CE standards and put operators at serious risk. As an employer, you are responsible for your worker’s safety!

CE-compliant safety guards

Ergonomics and Additional Features:

• Movable controller on an adjustable arm
• LED lighting for better comfort and visibility
• Front supports on linear guides

SCO – Oil Cooling System

Standard equipment — ensures stable machine operation parameters even during prolonged continuous use.

Tool clamping system:

• Standard four-sided sectional dies and sectional punches
• Manual AMADA-type (European) quick clamping system allowing fast tool change
• Punches are side-mounted and locked with bolts

Tool and die selection

The final bending result depends on proper selection of tools — the punch and die. CORMAK press brakes continuously measure bending parameters and can automatically correct deviations during the process for optimal results.

Depending on the press capacity, sectional punches and dies may vary in length.

Training and Machine Commissioning

It is possible to arrange professional training and machine commissioning carried out by a Cormak technician — this service is priced individually.

Contact our advisor to get more information.

Contact us

*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training — please contact our consultant for more details.
