CNC Lathe CKT500x1000 – precision and reliability in metalworking

CNC Lathe CKT500x1000 is an advanced numerically controlled lathe designed for precise metal machining in medium and large industrial plants. Equipped with Siemens Sinumerik 808D control and a hydraulic chuck, it ensures high accuracy, efficiency and ease of operation, meeting the requirements of modern production processes.

Main advantages of the CNC Lathe CKT500x1000

CNC Lathe for metal CKT500x1000 is a professional industrial solution combining advanced technology with a solid construction, dedicated to workshops requiring precision cutting. As an industrial lathe, it allows complex operations such as external, internal, and spherical turning, threading, drilling, grooving and contouring, ensuring top-quality finishes. Its key benefits include:

• Exceptional machining precision: Maximum turning diameter over bed 500 mm and over cross slide 280 mm, with surface roughness Ra1.6, guaranteeing excellent surface finish of machined parts.
• Flexible spindle: Speed range 200–1800 rpm (or 200–1200 rpm for a 91 mm bore) and spindle bore 75 mm (option 91 mm) enable machining of a wide variety of materials, from steel to light alloys.
• Intuitive control: Siemens Sinumerik 808D system with Siemens servo drives offers a user-friendly mode for operators of conventional machines, making the transition to CNC operation easier.
• Rigid construction: Net weight of 2,900 kg and dimensions of 2355×1520×1860 mm ensure stability during the machining of parts up to 1,000 mm long.
• Tool efficiency: 6-position tool turret (optional 8 positions) with 25×25 mm tools speeds up tool change, reducing production cycle time.
• Quick setup: Allows convenient tool setting, zero-point adjustment and corrections without programming – ideal for single-piece production.
• Increased safety: Controlled feed and speed limits allow precise and safe machine movements, minimising the risk of errors.
• Durability of components: Automatic lubrication system for gears and guideways reduces wear and extends machine service life.
• Optimal cooling: The cooling system maintains thermal stability, protecting tools and components during intensive machining.
• Versatile applications: Designed for precision turning in mechanical, automotive and tooling industries, suitable for both batch and small-series production.
• Operating economy: The main motor with 7.5 kW power (optional 11 kW) combines high performance with low energy consumption.
• Integration with machining cycles: Cooperation with machining cycles such as transverse turning, taper turning, threading or drilling requires only the input of basic parameters, without G-code knowledge.
• Advanced automation: Hydraulic 3-jaw chuck and hydraulic tailstock increase efficiency, especially in serial production.
• Customisation options: A wide range of options such as Fanuc Oi-TF control, chip conveyor, bar feeder or CAD/CAM software allow the machine to be tailored to specific needs.
• European safety standards: CE Declaration of Conformity confirms compliance with strict work safety regulations.

Construction and technology of the CNC Lathe CKT500x1000

Industrial CNC Lathe CKT500x1000 has been designed for reliability and precision under demanding production conditions. The key construction features include:

• Solid machine bed: The rigid structure with a net weight of 2,900 kg minimises vibrations, ensuring stability during machining.
• High-performance spindle: Bore 75 mm (option 91 mm) and speed 200–1800 rpm (or 200–1200 rpm) allow machining of various workpieces.
• Turret head: 6-position (option 8) with 25×25 mm tools ensures fast tool changes and operational flexibility.
• Hydraulic tailstock: With a maximum stroke of 120 mm, it supports precise workpiece clamping.
• Hydraulic 3-jaw chuck: Provides firm workpiece holding, increasing efficiency in serial production.
• Siemens servo drives: Guarantee smooth motion and high positioning accuracy.
• Automatic lubrication system: Central lubrication for gears and guideways reduces component wear.
• Cooling system: Maintains optimal temperature, improving machining quality and tool life.
• 24V halogen lighting: Provides excellent visibility of the working area, increasing safety and accuracy.

Precision and performance

Numerical lathe CKT500x1000 provides exceptional precision thanks to SIEMENS SINUMERIK 808D control and Siemens servo drives. Advanced fixed cycles such as transverse turning, taper turning, threading, grooving and contouring simplify programming and reduce machining time. With surface roughness of Ra1.6, axis feed rates X (8 m/min) and Z (10 m/min), and the ability to machine workpieces with a diameter up to 500 mm and length of 1000 mm, the machine ensures both high precision and productivity.

Applications of the CNC Lathe for metal CKT500x1000

CNC lathes for metal such as the CKT500x1000 are used in various industrial sectors, including:

• Mechanical industry: Production of shafts, sleeves, flanges and precision components.
• Automotive industry: Machining of engine parts, transmission and suspension components.
• Toolmaking industry: Manufacturing of threads, grooves and complex-shaped parts.
• Serial and small-batch production: Ideal for medium-series manufacturing as well as fast prototyping and individual part production in R&D departments.

The machine is an excellent choice for companies seeking a versatile and reliable CNC lathe.

Standard equipment

• Control system: SIEMENS SINUMERIK 808 Advanced
• Siemens servo drives
• Hydraulic 3-jaw chuck
• 6-position turret head
• Set of soft jaws
• Hydraulic tailstock
• Cooling system
• Automatic lubrication system for gears and guideways
• 24V halogen lighting
• User manual
• CE Declaration

Optional equipment*

• SIEMENS SINUMERIK 828D control
• Travelling steady rest
• 8-position turret head
• Hydraulic chuck
• Hydraulic tailstock
• Fixed steady rest
• Tool probe
• Chip conveyor
• Additional soft jaws
• Hard jaws
• Collet holders
• Finished part gripper
• Bar feeder
• Tool holders
• CAD/CAM software

*The price quoted applies to the machine only, excluding optional or additional accessories, installation, transport and training — please contact our consultant for more details.

Technical parameters

CNC control systems – SIEMENS and FANUC

CNC Lathe CKT500x1000 offers advanced CNC control systems such as SIEMENS SINUMERIK 808D, SIEMENS SINUMERIK 828D and FANUC Oi-TF, providing precision, reliability and ease of operation:

SIEMENS SINUMERIK 808 Advanced

• Intuitive interface: Easy to operate, ideal for smaller workshops and beginner users.
• Reliability: Durable construction resistant to harsh industrial conditions.
• Cost-effectiveness: Designed for standard turning and milling applications.

SIEMENS SINUMERIK 828D

• High computing power: Enables dynamic machining and execution of complex cycles.
• CAD/CAM integration: Simplifies cooperation with design software.
• Advanced functions: Toolpath optimisation and expansion with additional modules.

FANUC Oi-TF

• Stability: High reliability in serial and long-term production.
• Advanced turning cycles: Perfect for precise cutting operations such as threading and grooving.
• Intuitive operation: Clear interface speeds up programming.
