Conventional Universal Lathe Set CORMAK 410 x 1500 with Turning Tools and Live Centre

The CORMAK 410 x 1500 universal lathe is a professional conventional metal lathe designed for precision machining of shafts, bushings, threads, and tapered or cylindrical surfaces. Thanks to its extended 1500 mm centre distance, rigid bed construction and extensive standard equipment – including a 20×20 mm turning tool set and a precision live centre MK4 – it offers a complete solution for industrial facilities and metal workshops.

Main Features

• Extended centre distance – 1500 mm – allows machining of long shafts and large components.
• Rigid cast-iron bed and base – hardened and ground bed ways ensure high stability and vibration reduction.
• Large spindle bore – Ø52 mm – enables machining of tubes and large-diameter parts.
• Precision spindle bearings – reinforced design ensures long-term accuracy and smooth performance.
• Removable bed gap – allows machining of workpieces up to Ø580 mm.
• 3-axis digital readout (DRO) – optical scales provide accurate position control of the carriage and slides.
• 16 spindle speeds (45–1800 rpm) – full control over cutting parameters for any material.
• Direct thread selection – wide threading range (metric, inch, module, D.P.) without changing gear sets.

Design and Technology

The CORMAK 410 x 1500 conventional lathe is built for heavy-duty operation. Its one-piece 250 mm wide cast-iron bed provides excellent damping and machining stability, resulting in superior surface finish. The spindle, equipped with D1-6 CAMLOCK mount and MK6 taper, operates through a hardened and ground gear transmission for durability and low noise. A leadscrew and feed shaft ensure automatic longitudinal and cross feeds, as well as threading in both directions.

Precision and Productivity

The integrated 3-axis digital readout system enables precise control of carriage movement during all machining stages. The ergonomic control panel allows quick speed and feed adjustments, while the built-in thread dial indicator facilitates precise multi-pass threading. This makes the CORMAK 410 x 1500 lathe ideal for both single-piece and small-series production, offering repeatable accuracy and excellent efficiency.

Applications

The CORMAK 410 x 1500 universal lathe set is perfect for industrial production, tool rooms, maintenance departments and precision mechanics workshops. Capable of machining long and heavy parts, it serves industries such as automotive, mechanical engineering and maintenance services.

Standard Equipment

• Turning tool set 20×20 mm – 7 pcs (with replaceable inserts)
• Precision live centre MK4
• 6 vibration isolators
• 3-axis digital readout (optical scales)
• 3-jaw chuck 200 mm + full jaw set
• 4-jaw chuck 250 mm
• Faceplate 350 mm
• Fixed and travelling steady rests
• Fixed centre MK4
• Reducing sleeve MK6/MK4
• Full set of change gears
• Coolant system with pump
• Work light
• Oiler, wrenches and service tools
• CE-compliant safety guards
• User manual (EN) + CE declaration

Optional Equipment

• Taper-turning attachment
• Drill arbor MK4/B16
• Drill chuck B16 (3–16 mm)
• Cobalt drill set HSS-CO5 1–13 mm
• Cutting fluid ES-12 – 1L

Technical Specifications

Choose Precision and Versatility

Order the Conventional Universal Lathe Set CORMAK 410 x 1500 with complete equipment today and expand your machining capabilities. Contact our technical department for support or a quote for delivery and machine setup at your facility.
