Advantages of the laser welder
- Easy to operate – thanks to its thoughtful design and applied solutions, the operator can start work after a short training period.
- Low indirect radiation – only protective glasses are required to filter strong light during operation.
- Much faster welding than traditional methods – efficiency can increase from 3 to 10 times.
- Concentrated beam: slight structural change due to a small heat-affected area.
- Repeatability of welds – the weld seam is neat and the joints are highly durable.
- Very thin materials, such as 0.5 mm stainless steel, can be welded.
- Welding with or without wire (option*).
Technical specifications
| Maximum power |
3000 W |
| Laser wavelength |
1070 nm |
| Fibre length |
10 m |
| Operating modes |
Continuous / Modulated |
| Air pressure |
10 – 15 L/min |
| Welding speed |
0–215 mm/s |
| Automatic wire feeder |
Ø 0.8 – 2.0 mm |
| Maximum power consumption |
≤11.0 kW |
| Focal length |
150 mm |
| Cooling system |
Water-cooled |
| Operating voltage |
400V |
| Shielding gas consumption |
20 L/min |
| Dimensions |
600 × 1100 × 1100 mm |
| Approx. weight |
185 kg |
THICKNESS OF WELDED MATERIALS
|
Material
|
WELDER POWER
|
| 1000 W |
1500 W |
2000 W |
3000 W |
| Stainless steel |
0.5–3.0 mm |
0.5–4.0 mm |
0.5–5.0 mm |
0.5–8.0 mm |
| Mild steel |
0.5–2.5 mm |
0.5–3.5 mm |
0.5–4.5 mm |
0.5–8.0 mm |
| Galvanised steel |
0.5–1.2 mm |
1.5–1.8 mm |
1.5–4.0 mm |
1.5–7.0 mm |
| Aluminium |
0.5–1.2 mm |
1.5–1.8 mm |
1.5–4.0 mm |
1.5–7.0 mm |
| Brass |
0.5–1.2 mm |
1.5–1.8 mm |
1.5–2.5 mm |
1.5–4.0 mm |
LATEST GENERATION WELDING HEAD
- WOBBLE-type head;
- Automatic wire feeder included;
- Adjustable spot size 0–5 mm;
- High-power welding head allows multiple beam patterns: ○, ―, •, ꓷ, 0, ▲, 8;
- Integrated connections for shielding gases and cooling system;
- Replaceable nozzles allow welding at various angles;
- 10 m optical fibre connecting the head to the laser source;
- Welding parameters adjustable directly on the head – no need to approach the control panel;
- Full ergonomics – lightweight and flexible design allows welding even in hard-to-reach areas;
- Easy maintenance – quick and convenient replacement of the protective lens.
Automatic dual-roller wire feeder included
The wire feeding system is synchronised with the welder’s software. Its task is to supply filler material so that the operator can fully focus on working with the welding head.
WELDING MODES
Selecting the appropriate welding mode allows for optimal results. The welding mode should be selected according to the type and thickness of the welded material.
Set includes
- Laser welder with built-in cooling system
- Welding gun with focal adjustment and full accessory kit
- Fiber laser source
- Automatic wire feeder
- Set of cables
- Starter set of nozzles and protective glasses
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
