FIBER LF3015MB Fiber laser with a sheet feeder

A specialized fiber laser with an automatic sheet feeder. The fiber laser is also equipped with a vacuum holder enabling automatic unloading of the finished product, which significantly saves time and improves efficiency.

Have questions? Call us!

+48 25 631 00 27 ext.130

export@cormak.pl

Are you a member of the VIES group?

To use the VIES group, you must have a VAT number.

Yes - show prices with VAT 0%

Are you interested in this product?

Ask for price

I agree to the terms and conditions and the privacy policy

Fiber Lasers
designed and assembled in Poland

Fiber optics laser cutters constitute modern devices with many advantages. These are not only a perfect and more profitable alternative to the CO2 technology, but they also possess a lot of pros by themselves, such as improving the production by considerable margin and increasing its quality. FIBER technology allows for cutting sheets and other materials of various thickness: from very thin to very thick. The length of a wave in a FIBER laser is 1.064 micrometre long. These properties influence the intensity, which is a hundred times higher than in the case of CO2 devices of similar power.

The biggest advantages of the laser are

failure-free optical fiber cable
no elements that wear out
the source of the fiber optic laser takes 1/3 less space
high energetic efficiency - 100000 hours of work
universal applicability (specific metal sheets, carbon and stainless steel, copper, brass, aluminium, titanium)

Optical fiber laser

increases the efficiency by 80%
reduces the handling costs by 70%
saves 80% of energy
minimises the consumption of gas
saves space in the workplace by 30%

Unwinding machine

The machine unwinds the material from the roll. The width of the coil can be from 100-1300 mm wide and weigh up to 10 tons.

Leveling feeder

The feeder aligns the material with an accuracy of ± 0.01 mm

Automatic material unloading

The fiber laser is equipped with a vacuum holder enabling automatic unloading of the finished product, which significantly saves time and improves efficiency.

FIBER LF3015MB Fiber laser with a sheet feeder

Sliding gate made of annealed aircraft aluminium

The construction of the sliding gate is made of annealed aircraft aluminium, formed with a strength of 4300 tonnes, achieving unprecedented rigidity. Aircraft aluminium has many advantages: high rigidity (higher than cast iron), small mass, resistance to corrosion and oxidation as well as susceptibility to machining.

FIBER LF3015MB Fiber laser with a sheet feeder

RayTools head

Automatic focus regulation – Autofocus – The software automatically regulates the focusing lens during cutting metal sheets of various thickness. The speed of automatic focus regulation is 10 times higher than the speed of manual regulation.
Greater range of manual regulation – The range of regulation -10mm - + 10 mm, precision of 0.01 mm is useful in when it comes to materials of different thickness (0–20 mm) – Below 1500W.
Long durability. Collimating lenses and converging lenses possess a heat sink which cools down water, in turn decreasing the temperature of a cutting head, in order to improve the durability of the cutting head.

Bed welded using rectangular profiles

The inner structure of the bed forms a metal cell structure similar to a honeycomb patch, which is welded multiple rectangular tubes. Inside these tubes are stiffeners, which improve the durability and the stretching durability and stability of the guide rail, in order to avoid the deformation of the bed.

High durability, stability, stretching durability, amounting to 20 years of usage without deformations
The thickness of the rectangular sheet of a tube is 10 mm and 4500 kg

Technical parameters

Working area	3000x1500 mm
Power	1000W/2000W//3000W/4000W
Positioning repeatable accuracy	±0.03 mm/m
Maximum speed	120 m/min
Maximum acceleration	1,5/2G
Dimensions	400V 50Hz
Power supply	(5480+8034)x4850x(2650+300)mm
