Fibre laser cutting machines are modern devices that offer numerous advantages. They are not only an excellent and far more economical alternative to CO2 technology but also feature many benefits that increase productivity (by up to 70%) and improve production quality. FIBER technology enables cutting of sheets and other materials of varying thicknesses — from very thin to very thick. The wavelength in a FIBER laser is 1.064 micrometres, providing an intensity 100 times higher than that of CO2 systems of comparable power.
Main advantages of the laser:
- maintenance-free fibre source
- no consumable parts
- the fibre laser source requires about one-third less space
- high energy efficiency – 100,000 h of operation
- versatile applications (special steels, mild and stainless steel, copper, brass, aluminium, titanium)
Fibre laser
- increases productivity by 80%
- reduces maintenance costs by 70%
- saves 80% of energy
- minimises gas consumption
- saves 30% of workspace
Decoiler unit
The decoiler unwinds material from the roll. Coil width can range from 100 to 1300 mm, with a maximum coil weight of up to 10 tonnes.
Leveling feeder
The feeder levels the material with ±0.01 mm accuracy.
Automatic material unloading
The fibre laser is equipped with a vacuum gripper that enables automatic unloading of finished parts, greatly improving efficiency and reducing processing time.
Sliding gantry made of aged aerospace aluminium
The sliding gantry structure is made of aged aerospace aluminium formed under 4,300 tons of pressure, achieving exceptional stiffness. Aerospace aluminium offers multiple advantages: high rigidity (greater than cast iron), low weight, resistance to corrosion and oxidation, and excellent machinability.
Raytools cutting head
- Automatic focus adjustment – Autofocus. The software automatically adjusts the focusing lens when cutting sheets of varying thickness. The autofocus speed is ten times faster than manual adjustment.
- Wider manual adjustment range – adjustment range −10mm to +10mm, precision 0.01 mm, suitable for different material thicknesses (0–20 mm) below 1500W.
- Long service life. Collimator and focusing lenses are water-cooled, lowering the temperature of the cutting head and extending its operational life.
Welded bed made of rectangular profiles
The bed structure features an internal honeycomb design made of multiple welded rectangular tubes. Reinforcements inside the tubes improve strength, rigidity, and the stability of the guide rails, effectively preventing deformation. High strength, stability, and tensile resistance ensure up to 20 years of distortion-free operation.
Technical parameters
| WORKING AREA |
3000x1500 mm |
| POWER |
1000W–12000W |
| REPEATABLE POSITIONING ACCURACY |
±0.03 mm/m |
| MAXIMUM SPEED |
120 m/min |
| COIL SHEET WIDTH |
100–1300 mm |
| COIL WEIGHT |
10000 kg |
| MAXIMUM ACCELERATION |
1.5/2G |
| POWER SUPPLY |
400V 50Hz |
| DIMENSIONS |
(5480+8034)x4850x(2650+300) mm |
Cutting parameters
Actual parameters may vary depending on technical conditions and materials used.
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
