Fibre laser cutting machines are modern devices that stand out for their numerous advantages. They are not only an excellent and much more cost-effective alternative to CO2 technology, but also have many features that help increase production (by up to 70%) and improve its quality. FIBER technology allows cutting of sheets and other materials of various thicknesses — from very thin to very thick. The wavelength of a FIBER laser is 1.064 micrometres. These properties provide an intensity 100 times greater than that of CO2 systems of similar power.
MAIN ADVANTAGES OF THE LASER
- reliable optical fibre
- no consumable components
- fibre laser source occupies about 1/3 less space
- high energy efficiency – 100,000 h of operation
- universal application (special sheets, mild and stainless steel, copper, brass, aluminium, titanium)
Fibre Laser
- increases work efficiency by 80%
- reduces maintenance costs by 70%
- saves 80% of energy
- minimises gas consumption
- saves 30% of workshop space
Electric Clamping Chuck
The chuck grips the profile in two directions and automatically performs centring. The diagonal adjustment range is 20–200 mm.
Easy to Use
Wireless controller for convenient operation.
Automatic Tube Support
An intelligent tube support system eliminates deformation during the cutting of long tubes.
Technical Parameters
| TUBE DIAMETER |
20–200 mm |
| POWER |
1000W, 1500W, 2000W, 3000W, 4000W, 6000W |
| REPEATABLE POSITIONING ACCURACY |
±0.03 mm/m |
| DIMENSIONS |
11900×1580×2260 mm |
| POWER SUPPLY |
400V 50Hz |
Cutting Parameters
Actual parameters may vary depending on technical conditions and materials used.
