CNC Pipe Lathe CKT800x2000 130 mm Spindle Bore – Precision and Efficiency in Metal Machining
CNC Pipe Lathe CKT800x2000 130 mm Spindle Bore is an advanced numerically controlled lathe designed for precise machining of pipes and metal components in demanding industrial environments. Equipped with Siemens Sinumerik 808D control and a solid construction, it offers high precision, performance and reliability for professional use.
Main Advantages of the CNC Pipe Lathe CKT800x2000 130 mm Spindle Bore
CNC Pipe Lathe CKT800x2000 130 mm Spindle Bore combines advanced technology with a heavy-duty structure, providing users with significant production benefits. Key advantages include:
- Large working area: Centre distance 2000 mm, maximum turning diameter 800 mm and over cross slide 420 mm enable machining of long parts and pipes – ideal for mechanical, oil and energy industries.
- High precision: X/Z axis repeatability of 0.012/0.02 mm and 0.025 mm guarantees excellent surface quality, even for complex geometries.
- Optimal spindle bore: Spindle bore 130 mm (optional 220 mm) and spindle speed range 22–800 rpm with an 11 kW motor allow efficient machining of hard materials such as steel and titanium alloys.
- Exceptional stability: The 5000 kg machine body minimises vibration, ensuring stability during heavy-duty turning operations.
- Feed dynamics: Rapid feed speed X/Z 4/8 m/min and maximum travel 420/1850 mm reduce cycle time, improving productivity.
- Flexible configuration: Options such as Fanuc control, hydraulic chuck, steadies or 6- or 8-position tool turret allow full customisation to user requirements.
- User-friendly interface: Siemens Sinumerik 808D with simple operation and CAD/CAM compatibility simplifies programming and reduces operator training time.
- Cost efficiency: Compact dimensions 4907×2040×1855 mm and an 11 kW motor minimise energy consumption and operating costs.
- Versatility: Capable of machining pipes, shafts, flanges and other parts in a single production cycle — from light metals to high-strength alloys.
- Advanced cooling system: The standard coolant system provides effective heat dissipation, extending tool life and improving surface finish.
- Durability and reliability: High-quality components and robust design ensure long machine life, even in intensive production.
- Operational safety: CE-certified design compliant with European safety standards guarantees safe operation in industrial environments.
CNC Metal Lathe CKT800x2000 130 mm Spindle Bore is the perfect solution for production facilities requiring reliable and precise machining of long pipes and metal parts.
Design and Technology of the CNC Pipe Lathe CKT800x2000
CNC Pipe Lathe CKT800x2000 130 mm Spindle Bore has been designed for durability, precision and easy operation. Key components include:
Structure and Bed
The massive machine frame and wide bed ensure excellent rigidity and vibration damping. The 2000 mm centre distance and 800 mm turning diameter allow machining of long workpieces such as pipes and shafts with high stability.
Spindle and Drive
The spindle with a 130 mm bore (optional 220 mm) and a speed range of 22–800 rpm, powered by an 11 kW motor, guarantees high cutting performance. The standard 4-jaw chuck 520 mm (optional 3-jaw 400 mm) provides secure workpiece clamping.
Guideways and Drives
Linear guideways and precise servo drives ensure smooth motion on X/Z axes (travel 420/1850 mm) with rapid feed 4/8 m/min, reducing positioning errors and ensuring high dynamic performance.
Control System
The standard Siemens Sinumerik 808D (optional Siemens 828D or Fanuc Oi-TF) offers precise programming and process optimisation. The compact IP65-rated control panel ensures reliability in harsh environments, while the RS-232 interface allows easy CAD/CAM integration.
Precision and Performance
Industrial Lathe CORMAK CKT800x2000 130 mm Spindle Bore delivers outstanding precision thanks to its advanced CNC control system and robust construction. X/Z axis repeatability of 0.012/0.02 mm and 0.025 mm, combined with feed speed of 4/8 m/min, optimises tool paths, reduces machining cycles and increases productivity. The powerful 11 kW motor makes this machine ideal for both single-part and serial production of long components.
Applications of the CNC Pipe Lathe CKT800x2000
CNC Metal Lathe CORMAK CKT800x2000 130 mm Spindle Bore is used in demanding sectors such as:
- Oil and gas industry: Machining of pipes, flanges and fittings of smaller diameters.
- Machinery industry: Production of shafts, sleeves and structural parts.
- Machine building: Turning precise components for industrial machines and equipment.
- Energy sector: Machining of turbine and drive shaft components.
- Manufacturing workshops: Execution of both serial and custom orders requiring high precision and flexibility.
Thanks to the optimal spindle bore and advanced configuration options, this CNC lathe is the perfect choice for medium and large production plants.
CNC Control Systems – Siemens Sinumerik 808D, 828D and Fanuc Oi-TF
CNC Pipe Lathe CORMAK CKT800x2000 130 mm Spindle Bore offers professional CNC systems from renowned manufacturers such as Siemens and Fanuc, providing precision, performance and ease of operation.
Siemens Sinumerik 808D – Compact Control for Standard Applications
Sinumerik 808D is an economical CNC control system for metal lathes, providing:
- Intuitive interface: Dedicated keyboard and simple graphic display make operation easy.
- High reliability: IP65 protection ensures stable operation in workshop conditions.
- Advanced functions: Turning cycles and CAD/CAM integration support.
Siemens Sinumerik 828D – Advanced Control for Demanding Processes
Sinumerik 828D is a professional CNC control system for industrial lathes, offering:
- High computing power: Rapid data processing for dynamic and precise machining.
- Extended features: Advanced machining cycles, interpolation and tool path optimisation.
- Automation integration: Expandable with additional control modules.
Fanuc Oi-TF – Stability and Accuracy
Fanuc Oi-TF provides reliable CNC control for CNC lathes, offering:
- Operational stability: Precision during long-term serial production.
- Advanced turning functions: Threading, grooving and drilling.
- Simple operation: Fast programming and user-friendly interface.
Choose the CNC control system that best suits your needs to increase production efficiency and machining precision!
Technical Specifications
| Centre distance |
2000 mm |
| Maximum turning diameter |
800 mm |
| Maximum turning diameter over cross slide |
420 mm |
| Spindle bore |
130 mm |
| Tools |
4 (option 6, 8) |
| Spindle speed |
22–108, 60–300, 240–800 rpm |
| Maximum X/Z axis travel |
420/1850 mm |
| Rapid feed speed X/Z |
4/8 m/min |
| Axis repeatability X/Z |
0.012/0.02; 0.025 mm |
| Tailstock sleeve diameter |
100 mm |
| Maximum tailstock sleeve travel |
250 mm |
| Tailstock taper |
MT5 |
| Main motor power |
11 kW |
| Machine weight |
5000 kg |
| Overall dimensions |
4907 × 2040 × 1855 mm |
Standard Equipment
- Sinumerik 808D control system in Polish language
- 2 × manual 4-jaw chuck 520 mm
- 4-position tool post
- Set of soft jaws
- Manual tailstock
- Cooling system
- Automatic lubrication system for gears and guideways
- 24V halogen work light
- Operation manual in Polish
- CE Declaration of Conformity
Optional Equipment*
- Spindle bore 220 mm
- 4-position tool holder
- Electronic handwheels
- 3-jaw chuck 400 mm
- Hydraulic chuck and tailstock
- Control systems: Fanuc, Siemens 828D
- Fixed and travelling steadies
*The price quoted refers to the machine only and excludes optional/additional equipment, installation, transport and training — please contact our consultant for more details.
