CNC Pipe Lathe CKT1000x1500 Spindle Bore 270mm – precision and power in pipe machining
CNC Pipe Lathe CKT1000x1500 Spindle Bore 270mm is an advanced numerical lathe designed for precise machining of large pipes and metal components in demanding industrial applications. Equipped with Siemens Sinumerik 808D control and a solid construction, it ensures high performance, precision, and reliability.
Main advantages of the CNC Pipe Lathe CKT1000x1500 Spindle Bore 270mm
The CNC Pipe Lathe CKT1000x1500 Spindle Bore 270mm combines advanced technology with a heavy-duty structure, offering users major advantages in production processes. Key benefits include:
- Large working area: Centre distance 1500 mm, maximum swing over bed 1000 mm, and over carriage 620 mm allow machining of large pipes and components, ideal for the oil, gas, and shipbuilding industries.
- High precision: Axis repeatability X/Z of 0.012/0.02 mm and 0.025 mm ensures excellent surface quality even with complex geometries.
- Large spindle bore: Spindle bore 270 mm (optionally 220 mm) and spindle speed range 22–300 rpm with an 11 kW motor allow efficient machining of large-diameter pipes and hard materials such as steel and titanium alloys.
- Outstanding stability: A machine weight of 7500 kg and a massive body structure minimise vibrations, ensuring stability during heavy-duty operations.
- Feed dynamics: Rapid feed rates X/Z 4/8 m/min and maximum travel 1350/620 mm reduce cycle time and increase productivity.
- Configuration flexibility: Options such as Fanuc control, hydraulic chuck, steady rests, or 6- or 8-tool turret allow customisation for specific requirements.
- Intuitive operation: Siemens Sinumerik 808D control with a user-friendly interface and CAD/CAM compatibility simplifies programming and operation.
- Economy: Compact dimensions 4307x2040x1855 mm and an efficient 11 kW motor minimise energy consumption and operating costs.
- Versatile applications: Capable of machining pipes, shafts, flanges, and other components in a single production cycle — from light metals to high-strength alloys.
- Advanced cooling system: The standard cooling system ensures efficient heat dissipation, extending tool life and improving machining quality.
The CNC Metal Lathe CKT1000x1500 Spindle Bore 270mm is the ideal choice for production plants seeking a reliable, precise, and high-performance machine for machining large pipes and metal parts.
Construction and technology of the CNC Pipe Lathe CKT1000x1500
CNC Pipe Lathe CORMAK CKT1000x1500 Spindle Bore 270mm has been designed for durability, precision, and ease of operation. Key components include:
Construction and bed
The machine’s massive frame and wide bed provide exceptional rigidity and vibration damping. The centre distance of 1500 mm and a maximum swing over bed of 1000 mm allow machining of large workpieces such as pipes and shafts.
Spindle and drive
The spindle with a bore of 270 mm (optionally 220 mm) and speed range 22–300 rpm, driven by an 11 kW motor, ensures high cutting efficiency. The standard 630 mm 4-jaw chuck (optional 400 mm 3-jaw chuck) provides secure clamping of large parts.
Guides and drives
Linear guides and precision servo drives ensure smooth movement on the X/Z axes (travel 1350/620 mm) with rapid feed rates of 4/8 m/min, reducing positioning errors and guaranteeing high operational dynamics.
Control system
The standard Siemens Sinumerik 808D (optionally Siemens 828D or Fanuc Oi-TF) allows precise programming and process optimisation. The compact control panel with IP65 protection ensures reliability in harsh workshop conditions, and the RS-232 interface facilitates integration with CAD/CAM systems.
Precision and performance
Industrial Lathe CORMAK CKT1000x1500 Spindle Bore 270mm delivers high precision thanks to its advanced CNC system and robust design. Axis repeatability X/Z of 0.012/0.02 mm and 0.025 mm, combined with feed speeds of 4/8 m/min, allow toolpath optimisation, shorter cycles, and increased efficiency. The powerful 11 kW motor makes this lathe ideal for both serial and single-piece production of large parts.
Applications of the CNC Pipe Lathe CKT1000x1500
CNC Metal Lathe CORMAK CKT1000x1500 Spindle Bore 270mm is widely used across demanding industries, including:
- Oil and gas industry: Machining of large-diameter pipes, flanges, and fittings.
- Mechanical engineering: Production of shafts, sleeves, and structural elements.
- Shipbuilding: Turning of large parts such as drive shafts and structural components.
- Energy sector: Machining of turbine components, shafts, and other precision elements.
- Production workshops: Ideal for flexible serial and single-piece machining tasks.
With its large spindle bore and advanced configuration options, this CNC lathe is the perfect solution for medium and large-scale manufacturing facilities.
CNC Control Systems – Siemens Sinumerik 808D, 828D and Fanuc Oi-TF
CNC Pipe Lathe CORMAK CKT1000x1500 Spindle Bore 270mm offers professional CNC control systems from leading manufacturers such as Siemens and Fanuc, providing precision, efficiency, and ease of use.
Siemens Sinumerik 808D – compact control for standard applications
Sinumerik 808D is a cost-effective CNC control system for metal lathes, offering:
- Intuitive interface: Dedicated keypad and clear graphic screen simplify programming and operation.
- High reliability: Protection class IP65 ensures stable operation in harsh workshop conditions.
- Advanced functions: Supports turning cycles and CAD/CAM integration.
Siemens Sinumerik 828D – advanced control for demanding processes
Sinumerik 828D is a professional CNC system for industrial lathes, offering:
- High computing power: Fast data processing for dynamic and precise machining.
- Extended functionality: Advanced machining cycles, interpolation, and toolpath optimisation.
- Automation integration: Expandable with additional control modules.
Fanuc Oi-TF – stability and precision
Fanuc Oi-TF is a reliable CNC control system for CNC lathes, providing:
- Operational stability: Consistent accuracy during long-term serial production.
- Advanced turning features: Threading, grooving, and drilling cycles supported.
- Intuitive interface: Simplified programming for fast setup and operation.
Select the CNC control that best suits your needs to maximise efficiency and machining precision!
Technical parameters
| Centre distance |
1500 mm |
| Maximum swing over bed |
1000 mm |
| Maximum turning diameter over carriage |
620 mm |
| Maximum workpiece length (between chuck and tailstock) |
1500 mm |
| Spindle bore |
270 mm |
| Tool positions |
4 |
| Spindle speed (2 ranges) |
22–108 / 60–300 rpm |
| Maximum X/Z-axis travel |
1350 / 620 mm |
| Rapid feed rate X/Z |
4 / 8 m/min |
| Axis repeatability X/Z |
0.012 / 0.02; 0.025 mm |
| Tailstock quill diameter |
100 mm |
| Tailstock quill travel |
250 mm |
| Tailstock quill taper |
MT5 |
| Main motor power |
11 kW |
| Net weight |
7500 kg |
| Dimensions |
4307 × 2040 × 1855 mm |
Standard equipment
- Siemens Sinumerik 808D control (English interface)
- 2 × manual 4-jaw chuck 630 mm
- 4-position tool post
- Complete jaw set
- Manual tailstock
- Cooling system
- Automatic lubrication system for gears and guides
- 24V halogen work light
- User manual in English
- CE Declaration of Conformity
Optional equipment*
- Spindle bore 220 mm
- 6- or 8-position tool turret
- Manual handwheels
- 3-jaw chuck 400 mm
- Hydraulic chuck and tailstock
- Fanuc or Siemens 828D control
- Fixed and travelling steady rests
*The price quoted is for the machine only, excluding optional or additional accessories, installation, transport, and training — please contact our consultant for more details.
Why choose CORMAK?
As an experienced CNC machinery manufacturer, CORMAK has been providing reliable industrial solutions for over 20 years. Our CNC metal lathes meet the highest European quality standards and are supported by professional warranty and post-warranty service. With extensive warehouse facilities (over 15,000 m²) and a dedicated team of specialists, we offer comprehensive technical support and expert advice.
- Experience: Over 16 years in CNC Siemens control servicing.
- Quality: Machines built according to strict European safety standards.
- Support: Professional consultancy, fast warranty, and post-warranty service.
By choosing a CORMAK industrial lathe, you invest in precision, reliability, and long-term production efficiency.
Order the CNC Pipe Lathe CORMAK CKT1000x1500 Spindle Bore 270mm today!
Increase your production efficiency and machining precision with the CNC Pipe Lathe CORMAK CKT1000x1500 Spindle Bore 270mm. Contact our team for detailed information, a personalised quotation, or to schedule a machine demonstration.
