CNC Pipe Lathe CORMAK CKT800x3000 Spindle Bore 130mm SIEMENS SINUMERIK

Cormak Pipe Lathe is an advanced industrial machine designed for precise and efficient machining of large-diameter and long workpieces. With a turning diameter of up to 800mm and a 130mm spindle bore, the machine is ideal for processing pipes and sleeves used in the oil, gas, hydraulic and construction industries.

Equipped with a double chuck spindle system, the lathe ensures stable clamping of long workpieces, providing excellent accuracy and work safety. Its rigid design, powerful drive and easy operation make it a reliable tool for demanding production environments.

Have questions? Call us!

+48 25 631 00 27 ext.105

export@cormak.pl

Are you a member of the VIES group?

To use the VIES group, you must have a VAT number.

Yes - show prices with VAT 0%

VAT included

€45,448.50

Instructions in Polish
Service
Warranty 12/24 months
Delivery
Free

CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm – Precision and Efficiency in Metalworking

CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm is an advanced numerically controlled lathe designed for precision machining of pipes and metal components in demanding industrial environments. Equipped with Siemens Sinumerik 808D control and a solid construction, it provides excellent accuracy, reliability and efficiency in production applications.

Main Advantages of the CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm

CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm offers advanced technological solutions and a robust construction, delivering significant benefits in manufacturing processes. Its key advantages include:

Large working area: Centre distance of 3000mm, maximum turning diameter of 800mm and over cross slide 420mm allow machining of long components such as pipes, shafts and structural parts — ideal for the mechanical, energy and automotive industries.
High precision: Axis repeatability X/Z of 0.012/0.02mm and 0.025mm ensures outstanding surface quality even for complex geometries.
Optimised spindle bore: Spindle bore 130mm (optional 220mm) and spindle speeds of 22–800rpm powered by an 11kW motor allow efficient machining of pipes and parts made of steel, aluminium alloys and brass.
Exceptional stability: With a weight of 6000kg, the massive frame reduces vibrations and ensures stability during intensive turning operations.
Feed dynamics: Rapid feed rate of 4/8m/min in X/Z axes and travel range of 420/2850mm shorten cycle times, increasing productivity.
Flexible configuration: Options such as Fanuc control, hydraulic chuck, steadies or 6- or 8-position tool post adapt the machine to specific customer requirements.
Intuitive operation: Siemens Sinumerik 808D control with a simple interface and CAD/CAM compatibility simplifies programming and operation, reducing operator training time.
Energy efficiency: Dimensions of 5307x2040x1855mm and an 11kW motor reduce energy consumption and operating costs.
Versatile applications: Machining pipes, shafts, bushings and other parts in one cycle, from light metals to medium-hard materials.
Advanced cooling system: Standard cooling system ensures effective heat dissipation, extending tool life and improving surface finish.
Durability and reliability: High-quality components and robust construction guarantee long machine life even in demanding use.
Work safety: CE-compliant machine ensures safe operation in industrial environments.
Ease of integration: Compatible with automation systems and CAD/CAM software for seamless production line integration.

CNC Metal Lathe CKT800X3000 Spindle Bore 130mm is an ideal solution for production facilities requiring a reliable and precise machine for long workpieces and pipes.

Construction and Technology of the CNC Pipe Lathe CKT800X3000

CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm has been designed for durability, precision and ease of operation. Key components include:

Structure and Bed

The massive body and wide bed ensure outstanding rigidity and vibration damping. The 3000mm centre distance and 800mm maximum turning diameter allow machining of long workpieces such as pipes and shafts with excellent stability.

Spindle and Drive

The spindle with a 130mm bore (optional 220mm) and 22–800rpm speed range powered by an 11kW motor guarantees high cutting performance. The standard 4-jaw chuck 520mm (optional 3-jaw 400mm) ensures secure clamping of parts.

Guideways and Drives

Linear guideways and precision servo drives ensure smooth movement in X/Z axes (travel 420/2850mm) with rapid feed of 4/8m/min, minimising positioning errors and ensuring dynamic operation.

Control System

Standard Siemens Sinumerik 808D control (optional Siemens 828D or Fanuc Oi-TF) enables precise programming and optimisation of machining processes. The compact control panel with IP65 protection ensures reliability in workshop conditions, while the RS-232 interface supports CAD/CAM integration.

Precision and Performance

Industrial Lathe CKT800X3000 Spindle Bore 130mm ensures high machining precision thanks to its advanced CNC control and robust structure. Axis repeatability of 0.012/0.02mm and 0.025mm, combined with rapid feed rates of 4/8m/min, optimise tool paths, reduce machining cycle time and increase efficiency. The powerful 11kW motor makes the machine ideal for both serial and single-piece production.

Applications of the CNC Pipe Lathe CKT800X3000

CNC Metal Lathe CKT800X3000 Spindle Bore 130mm is designed for demanding industrial sectors, such as:

Machinery industry: Production of shafts, bushings and structural components.
Automotive industry: Machining of drive shafts, suspension parts and precision fittings.
Energy sector: Turning components such as turbine parts and long shafts.
Workshops and manufacturing plants: Single-part and batch production requiring high accuracy and flexibility.
Oil and gas industry: Machining of pipes and smaller-diameter fittings.

With its large working envelope and customisable configuration options, this CNC lathe is a perfect choice for medium and large-scale production facilities.

CNC Controls – Siemens Sinumerik 808D, 828D and Fanuc Oi-TF

CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm is available with professional CNC controls from leading manufacturers such as Siemens and Fanuc, offering reliability, precision and ease of use.

Siemens Sinumerik 808D – Compact Control for Standard Applications

Sinumerik 808D is an economical CNC control for metal lathes offering:

Intuitive interface: Dedicated keyboard and simple graphic display for easy programming and operation.
High reliability: IP65 protection ensures stable operation under workshop conditions.
Advanced functions: Supports turning cycles and CAD/CAM integration.

Siemens Sinumerik 828D – Advanced Control for Complex Processes

Sinumerik 828D is a professional CNC system for industrial lathes, providing:

High processing power: Fast data handling for dynamic and precise machining.
Extended features: Complex turning cycles, interpolation and optimised tool path control.
Automation integration: Expandable with additional control modules.

Fanuc Oi-TF – Stability and Accuracy

Fanuc Oi-TF is a reliable CNC control for metalworking lathes, offering:

Stable operation: Maintains precision in long-term serial production.
Comprehensive turning functions: Supports threading, grooving and drilling cycles.
User-friendly interface: Simplified programming and operation.

Choose the CNC control that fits your production needs to maximise efficiency and machining precision!

Technical Parameters

Centre distance	3000mm
Maximum turning diameter	800mm
Maximum turning diameter over cross slide	420mm
Spindle bore	130mm
Tool stations	4 (option 6, 8)
Spindle speed	22–108, 60–300, 240–800rpm
Maximum X/Z axis travel	420/2850mm
Rapid feed X/Z axis	4/8m/min
Repeatability X/Z axis	0.012/0.02; 0.025mm
Tailstock sleeve diameter	100mm
Tailstock sleeve travel	250mm
Tailstock sleeve taper	MT5
Motor power	11kW
Weight	6000kg
Dimensions	5307 x 2040 x 1855mm

Standard Equipment

Sinumerik 808D control system
2 × manual 4-jaw chuck 520mm
4-position tool post
Set of soft jaws
Manual tailstock
Cooling system
Automatic lubrication system for gears and guideways
24V halogen work light
CE declaration of conformity

Optional Equipment*

Spindle bore 220mm
4-position tool post
Manual handwheels
3-jaw chuck 400mm
Hydraulic chuck and tailstock
Controls: Fanuc, Siemens 828D
Fixed and travelling steadies

*The price shown applies to the base machine only, excluding optional or additional equipment, installation, transport and training — please contact our consultant for details.

Why Choose CORMAK?

As an experienced manufacturer of CNC machines, CORMAK has been delivering reliable industrial solutions for over 20 years. Our CNC lathes for metal meet the highest quality standards, carry European safety certifications and are supported by a professional service network. With an extensive warehouse facility (over 15,000m²) and a team of specialists, we offer comprehensive technical support and consultancy.

Experience: 16 years of service and support for Siemens CNC systems.
Quality: Machines compliant with European safety standards.
Support: Professional consultancy, fast warranty and post-warranty service.

By choosing a professional industrial lathe from CORMAK, you invest in precision, reliability and long-term production efficiency.

Order the CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm Today!

Boost your productivity and machining precision with the CNC Pipe Lathe CKT800X3000 Spindle Bore 130mm. Contact our team for more information, an individual quote or to arrange a demonstration of the machine.
