CORMAK Electric Pallet Truck – the perfect solution for warehouse and production handling
The CORMAK electric pallet truck is a highly efficient and reliable machine designed for transporting heavy loads in warehouses, production halls, and logistics centres. With a load capacity of 1500 kg, this truck enables easy pallet and cargo handling over short and medium distances, ensuring comfort and high work efficiency.
Main Advantages
- Load capacity of 1500 kg – enables safe and efficient handling of large and heavy goods in various operational conditions.
- Electric lifting system – provides smooth load lifting up to 190 mm, ensuring precision and safety during material handling.
- Easy manoeuvrability – electric drive allows quick and quiet movement throughout the facility, eliminating operator fatigue.
- Speed control potentiometer – allows for precise adjustment of travel speed, enhancing safety and preventing collisions.
- “Turtle” mode – enables slow, controlled movement of the truck for precise operations in confined areas.
- Integrated safety systems – electromagnetic brakes, belly safety switch and horn provide maximum operator and workplace protection.
Construction and Technology
The CORMAK pallet truck is equipped with a 24V/20Ah lithium-ion battery, ensuring up to 3 hours of operation on a single charge. With a fast charging time of just 2.5 hours, it’s ready for continuous use with minimal downtime. The battery can be easily replaced, enabling uninterrupted work in multi-shift operations.
Polyurethane wheels (80/210 mm) ensure excellent grip and smooth, quiet movement across various warehouse floors. Its solid, heavy-duty frame provides long service life and high resistance to mechanical wear, making it a dependable tool for demanding environments.
Precision and Performance
The truck features an electromechanical brake for safe stopping, which is crucial in high-traffic warehouse operations. Additionally, the “turtle” driving mode allows for precise control in narrow aisles, reducing collision risk. The speed control potentiometer enables smooth acceleration and braking, ensuring full control over every movement and increasing safety and accuracy during handling tasks.
Applications
The CORMAK electric pallet truck is a versatile solution perfect for:
- Warehouses and distribution centres requiring fast and safe load handling,
- Production facilities for moving materials between workstations,
- Operations in narrow warehouse aisles or loading platforms,
- Environments where precision and operator safety are top priorities.
Standard Equipment
- 24V/20Ah lithium-ion battery
- Polyurethane wheels (80/210 mm)
- Electromechanical brake system
- Speed control potentiometer
- “Turtle” precision driving mode
- Built-in charger included
Technical Data
| Load capacity |
1500 kg |
| Turning radius |
1300 mm |
| Fork height (raised) |
190 mm |
| Fork height (lowered) |
85 mm |
| Fork length |
1000 mm |
| Fork width |
550 mm |
| Wheel diameter |
80/210 mm |
| Battery voltage / capacity |
24V / 20Ah Li-ion |
| Working time on a single charge |
up to 3 h |
| Charging time |
2.5 h |
| Drive motor power |
0.75 kW |
| Lifting motor power |
0.8 kW |
| Brake type |
Electromechanical |
| Travel speed (loaded / unloaded) |
3.5 / 4.5 km/h |
| Weight |
130 kg |
| Dimensions (L×W×H) |
1500×550×1300 mm |
Order the CORMAK electric pallet truck today and improve your pallet handling efficiency. Contact our sales department or add it to your cart to receive a tailored offer and more information!
