Fibre laser cutters are modern machines with numerous advantages. They are not only an excellent and much more cost-effective alternative to CO2 technology, but they also offer many benefits that help increase production (up to 70%) and improve its quality. FIBER technology enables cutting of sheets and other materials of various thicknesses — from very thin to very thick. The wavelength of a FIBER laser is 1.064 micrometres. These features result in an intensity 100 times higher than in CO2 machines of comparable power.
MAIN ADVANTAGES OF THE LASER
- reliable optical fibre
- no consumable components
- fibre laser source occupies about 1/3 less space
- high energy efficiency – 100,000 h of operation
- universal application (special sheets, mild and stainless steel, copper, brass, aluminium, titanium)
Fibre Laser
- increases work efficiency by 80%
- reduces maintenance costs by 70%
- saves 80% of energy
- minimises gas consumption
- saves 30% of floor space
Electric Clamping Chuck
The chuck grips the profile in two directions and automatically performs centring.
Easy to Use
Wireless controller for easy operation.
Automatic Tube Support
An intelligent tube support system is used to eliminate deformation problems during the cutting of long tubes.
Part Collection (option*)
The cut parts fall onto a receiver from which they can be further transported.
Semi-Automatic Feeder (option*)
The feeder automatically supplies the workpiece, reducing the cutting process time to a minimum.
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
Technical Parameters
| TUBE DIAMETER |
20–240 mm |
| POWER |
3000W |
| REPEATABLE POSITIONING ACCURACY |
±0.02 mm/m
|
| POWER SUPPLY |
400V 50Hz
|
Cutting Parameters
Actual parameters may vary depending on technical conditions and materials used.
