Fibre laser cutting machines are modern devices distinguished by numerous advantages. They are not only an excellent and much more cost-effective alternative to CO2 technology but also have many features that allow production to grow (by up to 70%) and improve its quality. The FIBER technology enables cutting sheets and other materials of various thicknesses, from very thin to very thick. The wavelength in a FIBER laser is 1.064 micrometres. These properties affect the beam intensity, which is 100 times higher than that of CO2 machines of similar power.
MAIN ADVANTAGES OF THE LASER
- maintenance-free optical fibre
- no wearing parts
- the fibre laser source occupies around one-third less space
- high energy efficiency – 100,000 h of operation
- versatile use (special sheets, mild and stainless steel, copper, brass, aluminium, titanium)
Fibre Laser
- increases work efficiency by 80%
- reduces maintenance costs by 70%
- saves 80% of energy
- minimises gas consumption
- saves 30% of workshop space
Electric Clamping Chuck
The chuck grips the profile in two directions and automatically performs profile alignment.
Easy to Use
Wireless controller for easier operation.
Automatic Tube Support
An intelligent tube support system has been applied, which solves deformation problems occurring when cutting long tubes.
Workpiece Receiver (option*)
Cut parts fall onto the receiver, from which they can be further transported.
Semi-Automatic Feeder (option*)
The feeder automatically delivers the workpiece, reducing cutting time to a minimum.
Technical Parameters
| TUBE DIAMETER |
20–170 mm |
| POWER |
1000W |
| REPEATABLE POSITIONING ACCURACY |
±0.02 mm/m
|
| POWER SUPPLY |
400V 50Hz
|
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training — please contact our consultant for more details.
Cutting Parameters
Actual parameters may vary depending on technical conditions and materials used.
