Screw Compressor CORMAK LUFT 700 – Power and Precision for Your Business
Looking for a professional solution to supply pneumatic tools in your workshop, paint shop or a small production line? The CORMAK LUFT 700 Screw Compressor is the ideal choice. With its 5.5 kW motor power and an impressive actual output of up to 690 L/min, it provides a consistent supply of compressed air necessary for the efficient operation of impact wrenches, blow guns and spray tools.
This model is designed for continuous operation, making it perfect for demanding applications such as tyre services, small automotive workshops or small-scale production plants. Investing in the CORMAK screw compressor means taking a significant step towards improving workplace comfort – say goodbye to noisy piston compressors and enjoy quieter and more stable operation.
The LUFT 700 is distinguished by its direct-drive system, which provides greater efficiency and lower power losses compared to belt-driven models. This innovative solution ensures optimal utilisation of motor power and therefore higher efficiency with reduced energy consumption.
The maximum pressure generated by this screw compressor is 10 bar. Full control over the machine’s operating parameters is provided by the intuitive MAM electronic control panel, which gives you access to all key compressor information, enhancing flexibility and process control.
✅ Pressure: up to 10 bar | ✅ Output: up to 690 L/min | ✅ Power: 5.5 kW
CORMAK Screw Compressors: When You Expect the Highest Quality and Performance!
Looking for solutions that exceed market standards? CORMAK screw compressors are synonymous with innovation and reliability, designed for the most demanding industrial applications.
- Innovative design: Our compressors are based on advanced engineering and European manufacturing precision. The solid construction, enhanced with modern components, guarantees long-lasting and trouble-free operation under all conditions.
- Quiet operation and comfort: Designed with attention to every detail, our compressors feature exceptionally low noise levels. Effective soundproofing and vibration reduction systems ensure a comfortable working environment, improving operator concentration and well-being.
- Intelligent control: The intuitive MAM electronic control panel is the command centre of your compressor. It allows precise monitoring of parameters, maintenance planning and quick diagnostics, ensuring stability and protection of key components.
- Adaptability: We understand that every application is unique. CORMAK compressors can be configured with additional air treatment systems, allowing perfect adaptation to the specific requirements of your industry.
- Dynamic operating pressure: Automatic pressure regulation ensures that the compressor delivers exactly the amount of air required at any given moment, maximising energy efficiency and reducing losses.
- Sustainability: We focus on environmentally friendly solutions. The energy-saving technologies used in our compressors not only reduce your energy costs but also minimise environmental impact, while the optional heat recovery function allows optimal energy reuse.
CORMAK: Technology that drives your success!
Main Advantages of the 5.5 kW Induction Motor
- Stable system pressure: The compressor maintains a consistent pressure in the compressed air system, which is crucial for the proper functioning of pneumatic machines and tools, preventing pressure fluctuations and improving process precision.
- Extended component life: The belt transmission effectively absorbs vibrations and shocks, reducing mechanical loads on the screw block, bearings, coupling and motor itself. This translates into longer compressor life and lower servicing and spare part costs.
- Quieter operation: The specially designed housing with soundproof panels ensures low noise emission. This improves acoustic comfort in the workplace, which is essential for both operators and the surrounding environment.
- Greater flexibility and adaptability: The compressor efficiently handles a wide range of air demand levels, making it an ideal solution for companies where air consumption fluctuates throughout the day, week or month.
- Advanced control and diagnostics: The integrated control panel offers extensive functions for monitoring performance parameters, error diagnostics, remote control and maintenance scheduling, giving the user full control and system optimisation.
The combination of proven reliability of the induction motor with intelligent control makes this screw compressor a highly efficient, economical and versatile source of compressed air, perfectly suited to the dynamic demands of modern industry.
Screw Module – The Heart of Your Compressor
High-quality CORMAK screw compressors, such as the LUFT 700 model, are built around technologically advanced screw modules that determine their performance and reliability. By using proven solutions and innovative engineering, CORMAK ensures that every module is refined in every detail to meet the requirements of even the most intensive operation.
Key features of CORMAK screw modules:
- Modern technology and efficiency: Screw modules provide excellent performance and exceptional operational efficiency. Their design focuses on achieving maximum output with minimal energy consumption.
- Precision and control: Thanks to advanced technical solutions, the screw modules enable precise control of the compressed air generation process, resulting in stable pressure and optimal performance of the entire pneumatic installation.
- Durability and reliability: The screw modules used in CORMAK compressors are designed for longevity. Their robust construction and use of high-quality materials ensure reliability even in demanding industrial conditions, minimising downtime and maintenance requirements.
By choosing a CORMAK compressor, you invest in technology developed through years of experience and continuous innovation, directly translating into increased efficiency and productivity for your business.
Intuitive CORMAK Control Panel – Full Control at Your Fingertips
In CORMAK screw compressors, such as the LUFT 700 model, a key component ensuring reliability and work optimisation is the advanced MAM control panel. Designed for efficient compressed air system management, this controller enables real-time monitoring and quick response to all operating parameters.
What does the CORMAK control panel offer?
- Comprehensive monitoring: The panel allows continuous tracking of all key compressor operating parameters such as pressure, temperature and operating status.
- Easy parameter adjustment: Thanks to the intuitive interface, the user can easily modify operating settings and parameters, adapting them to the current system requirements.
- Instant notifications: The controller is programmed to respond quickly to any operational events. In the event of irregularities such as faults or required maintenance, an appropriate notification is displayed on the screen.
The CORMAK control panel guarantees peace of mind and performance, allowing precise management of your compressed air system.
Important!
By choosing our offer, you receive equipment directly from the manufacturer with long-standing experience in compressor production and sales.
Technical Specifications:
Screw Compressor LUFT 700
| Motor power |
5.5 kW |
| Voltage |
400V / 50Hz |
| Dimensions |
810 × 610 × 850 mm |
| Weight |
120 kg |
| Performance |
0–6 bar – average 690 L/min
At 6 bar – 650 L/min
At 8 bar – 650 L/min
At 10 bar – 630 L/min |
| Outlet connector diameter (G) |
1/2" |
200L AIR RECEIVER WITH FITTINGS – HIGH-QUALITY PRESSURE TANK FOR COMPRESSED AIR SYSTEMS
The CORMAK air receiver with a capacity of 200 litres and a working pressure of 11 bar is a reliable solution for storing compressed air in industrial plants, workshops and pneumatic installations. The solid steel construction, compliance with EU directives and UDT certification make this receiver an essential component of any compressed air system. Thanks to its optimised design and high pressure resistance, it serves both as an air storage buffer and a stabilising element for compressor operation.
Main Advantages of the 200L CORMAK Pressure Tank
- Professional pressure design – made of high-quality 4 mm thick steel, resistant to pressure and corrosion.
- UDT certification and CE marking – compliance with European safety and quality standards.
- Working pressure of 11 bar – suitable for most pneumatic systems, including high-pressure applications.
- High capacity – 200 litres – ensures stable supply to pneumatic systems and reduces compressor start frequency.
- Multi-connection system – six connectors with diameters 1/2", 1" and 2" provide flexible connection to various installations.
- High-quality finish – durable anti-corrosion coating applied both inside and outside the receiver.
- Space-saving design – the vertical configuration allows efficient installation even in compact spaces.
Design and Technology – A Robust Construction for Demanding Applications
This air receiver has been designed for intensive industrial use. The body made of structural steel with 4 mm wall thickness guarantees resistance to pressures up to 11 bar and long service life. All welds are subject to strict quality control, and the surfaces are protected with a corrosion-resistant coating resistant to chemical and environmental exposure.
The tank is fitted with a nameplate bearing the CE mark and UDT unit number, confirming its approval for operation within the EU. The set includes complete technical documentation, a pressure vessel passport and material certificates.
Precision and Performance – Stable Pressure and Extended Compressor Life
With its 200-litre capacity, the receiver acts as an air buffer, stabilising system pressure throughout the pneumatic network. This ensures consistent operation of pneumatic equipment and significantly extends compressor life by reducing the number of start/stop cycles. The vertical design allows compact installation, which is particularly valuable in limited spaces.
A properly matched compressor air receiver minimises pressure drops and prevents system overloads, improving overall efficiency and safety of the pneumatic system.
Applications – Versatility in Industrial and Workshop Use
CORMAK pressure vessels are widely used across various industries, including automotive workshops, production facilities, construction companies and central air systems. Owing to their durability and pressure resistance, they serve as:
- Compressor air tanks – for storing compressed air in pneumatic supply systems,
- Compressor receivers – pressure buffers reducing compressor operation frequency,
- Air reservoirs – supplying pneumatic tools and machinery continuously,
- Components of industrial automation and spray-painting systems,
- Essential parts of pneumatic control installations.
Standard Equipment
- Connection ports: 6 pcs – diameters 1/2", 1", 2"
- Nameplate with CE marking
- UDT unit notification number
- Full technical documentation and pressure vessel passport
- Internal and external anti-corrosion coating
Included Accessories
- Two 1/2” plugs
- One 1/2” nipple
- One 1/2” tee fitting
- One 1/2” to 1/4” reducer
- One 1/4” pressure gauge
- Two 1” to 3/4” reducers
- One 1/2” ball valve
Why Choose CORMAK Air Receivers?
- Proven quality – manufactured in accordance with PED 2014/68/EU directives
- Safety – UDT-compliant, resistant to overload and overpressure
- Durability – resistant to corrosion and mechanical damage
- Functionality – compatible with most piston and screw compressors
- Availability – offered in various capacities and configurations (vertical, horizontal)
Technical Specifications:
200L Pressure Vessel
| Weight (kg) |
80 |
| Connections |
6 |
| Connection sizes |
1/2", 1", 2" |
| Dimensions |
166.5 × 45 cm |
| Tank capacity (L) |
200 |
| Working pressure (bar) |
11 |
| Wall thickness (mm) |
4 |
| Diameter (mm) |
Ø 450 |
| Height (mm) |
1665 |
Choose Quality and Safety – Choose a CORMAK Air Receiver
If you are looking for an air receiver that guarantees reliability, UDT compliance and high efficiency for your pneumatic installation, the 200L CORMAK model is the perfect choice. We offer not only a durable product but also full technical support, spare parts availability and expert advice for correct compressor tank selection.
Order your CORMAK pressure tank today and improve the efficiency and safety of your pneumatic system. Contact our technical department or place your order online!
Important!
The safety valve is not included and must be purchased separately.
Contact us and order a unit tailored to your system!
