Panelsaw CORMAK PS315-2000 with Scoring Unit – compact professional saw for woodworking
The CORMAK PS315-2000 Panelsaw with scoring blade is a solid, precise and universal panelsaw designed for joinery, furniture production and board processing workshops. With a compact 2000 mm sliding table, robust guides and an efficient scoring system, this model is perfect for serial cutting of MDF, HDF, plywood and solid wood.
Main advantages of the machine
- Panelsaw with scoring blade – dual-blade system ensures chip-free cutting even on laminated and single-sided coated materials.
- Stable and durable structure – a strong frame, cast iron tables and steel guides ensure long service life and resistance to deformation.
- Wide adjustment range – blade tilt from 90° to 45° and adjustable main blade height allow for a variety of precise cuts.
- High blade speed – 5800 rpm on the main blade guarantees smooth, burn-free cutting.
- Dust extraction compatibility – built-in extraction port enables connection to a dust removal system.
- Safety and ergonomics – blade guard, measuring fence and safety elements increase comfort and operator safety.
Design and technology
The PS315-2000 panelsaw is designed for maximum rigidity and reliability. Its structure is based on a heavy-duty steel frame, while the main working surfaces are made of precision-ground cast iron. The main cutting blade (⌀315 mm) works in combination with a scoring blade (⌀90 mm), eliminating chipping and splintering. The machine is powered by two separate drives, allowing independent operation of both cutting systems.
The sliding carriage runs on a precision linear guide, and clear measurement scales for length and angle simplify setup and adjustment during cutting.
Precision and performance
The CORMAK PS315-2000 Panelsaw is optimised for high accuracy and ease of use. With spindle speeds of 5800 rpm (main blade) and 4000 rpm (scoring blade), the cuts are smooth and free of burrs, minimising the need for secondary finishing. The adjustable blade tilt system enables precise bevel cuts without repositioning the workpiece.
Applications
The PS315-2000 is a versatile panelsaw suitable for:
- professional joinery workshops,
- furniture and wooden component production,
- workshops cutting MDF, HDF, OSB, plywood and solid wood,
- manufacturers of structural and finishing elements.
Standard equipment
- Main cutting blade
- Scoring blade
- Sliding table 2000 mm with support
- Rip and crosscut fences
- Mitre cutting guide
- Blade guard with dust extraction outlet
- Extension table
- Cam clamp
- Tilt angle indicator
- User manual
- CE declaration
Optional equipment*
- Additional cutting blades
- Chip extraction system
- Pneumatic clamping beam
- Table extensions
*The price quoted refers to the machine only, excluding optional/additional accessories, installation, transport and training — please contact our consultant for details.
Technical data
| Sliding table length [mm] |
2000 |
| Cutting width [mm] |
1220 |
| Blade tilt [°] |
45 |
| Cutting height at 45° [mm] |
80 |
| Cutting height at 90° [mm] |
100 |
| Maximum blade diameter [mm] |
315 |
| Maximum scoring blade diameter [mm] |
100 |
| Main blade speed [rpm] |
5800 |
| Scoring blade speed [rpm] |
4000 |
| Motor power [kW] |
3.8 |
| Power supply |
3-phase, 400V |
| Weight [kg] |
350 |
| Warranty [months] |
12 |
| User manual |
included |
| CE certification |
yes |
Looking for a reliable panelsaw for precision board cutting? Choose the CORMAK PS315-2000 Panelsaw with Scoring Unit – a compact and professional solution for your workshop. Contact us to get a tailored technical offer today.
