The machine is manufactured in accordance with current European Union standards and is CE certified, accompanied by an EU Declaration of Conformity. The control panel and safety systems comply with current health and safety regulations. The spindle and gear guards are fitted with microswitches that provide additional operator protection.
KEY ADVANTAGES OF THE MACHINE:
- Digital depth readout for drilling and milling
- Integrated work light built into the machine body
- Durable and professional construction ensuring long service life
- Multi-functionality: enables both drilling and milling operations in one unit
- Reliable belt-driven transmission system
- Spindle mounted on precision ball bearings
- Adjustable spindle height for different applications
- Through-spindle with a threaded end for mounting cutting heads
- Safety switch with IP54 protection class for improved operator safety
- Quiet, efficient electric motor ensuring comfortable operation
- ✔ All mechanical components, including pulleys, are made entirely of metal – for maximum durability and reliability
ORIGINAL ZX7016 – precision and stability as standard
The machine is equipped with a solid, heavy-duty cross table, enabling smooth and precise two-axis (X/Y) movement for accurate machining. A machine vice can be mounted directly on the working table (available as an optional accessory). The cross table is an integral part of the machine’s structure, guaranteeing rigidity and reliability during operation.
Technical parameters:
| Max drilling capacity |
16 mm |
| Max vertical milling diameter |
12 mm |
| Max face milling width |
40 mm |
| Motor power S1/S6 |
0.55 kW / 0.75 kW |
| Motor speed |
1420 rpm |
| Voltage / frequency |
230 V / 50 Hz |
| Table size (L × W) |
420 × 152 mm |
| Table travel (Y-axis) |
115 mm |
| Table travel (X-axis) |
230 mm |
| Column–spindle distance |
180 mm |
| Spindle nose height from table |
155 – 355 mm |
| Spindle quill travel |
77 mm |
| Spindle taper |
MK2 |
| Spindle speeds |
320, 400, 500, 650, 800, 900, 1350, 1450, 1800, 1900, 2700, 3300 rpm |
| T-slot width and spacing |
12 × 80 mm |
| Weight |
75 kg |
Standard equipment
- Drill chuck 3–16 mm
- Drill chuck arbor
- Cross (working) table
- Hand tools set
- Operating manual (DTR / PL)
