Dual-Column Semi-Automatic Metal Bandsaw CORMAK BS1200H

Dual-Column Bandsaw CORMAK BS1200H – ultimate precision in cutting large workpieces

CORMAK BS1200H is an advanced dual-column metal bandsaw designed for demanding cutting processes of large-scale components. With its semi-automatic cycle, smooth blade speed adjustment, and robust cast-iron arm construction, the machine guarantees maximum precision, reliability, and operational safety. It is the ideal solution for industrial facilities that require dependable equipment for cutting pipes, bars, and steel profiles up to 1200 mm in diameter.

Main advantages of the machine

• Semi-automatic work cycle – full automation of the cutting process after activation.
• Rigid dual-column design – vibration elimination and improved accuracy.
• Smooth blade speed adjustment – from 15 to 80 m/min, adapted to the material type.
• Cutting blade 11200 × 67 × 1.6 mm – suitable for intensive cutting of large cross-sections.
• Safety system – automatic shutdown in the event of blade breakage.
• Total power 18.95 kW – ensures stable operation even under heavy loads.

Design and technology

The machine features a massive arm made from a single cast-iron piece, providing maximum rigidity. The blade guides, composed of bearings and carbide inserts, ensure cutting path stability. The metal bandsaw BS1200H is equipped with a modern cooling system and a powered cleaning brush, which extend the blade’s service life and improve cutting quality. The ergonomic control panel allows for quick adjustment of working parameters.

Precision and performance

By combining modern components such as ABB motors, carbide guides, and a precise hydraulic system, this machine provides outstanding accuracy and repeatability of cuts. Vibration-free operation and full control over cutting parameters enhance productivity and reduce the wear of consumable materials.

Applications

The Dual-Column Bandsaw CORMAK BS1200H is used in heavy industry, construction plants, steel companies, and machining centres where precise cutting of profiles, pipes, and large steel components is required. It is also suitable for continuous operation and serial production of structural elements.

Standard equipment

• Control panel with a clear interface
• Powered blade cleaning brush
• Cooling system with a closed circuit
• Bimetallic cutting blade included
• CE Declaration of Conformity
• User manual

Technical data

Choose power, stability, and maximum precision – opt for the CORMAK BS1200H bandsaw and boost your production efficiency!
