Pipe and Profile Belt Grinding Machine CORMAK MS2000 – professional processing of metal components
The CORMAK MS2000 pipe and profile belt grinder is a modern metal belt grinding machine designed for precise and efficient grinding of steel pipes, box profiles and flat surfaces. The machine performs excellently wherever processing speed, surface finish quality and operator comfort are crucial. With its solid design, powerful motor and dust collection system, the CORMAK MS2000 metal grinder is ready for continuous use in industrial environments.
Main advantages of the machine
- Prism jaw clamping system – ensures secure and stable fixing of pipes with diameters from 20 to 76.1 mm, as well as profiles and flat bars.
- Two-speed belt drive – allows adjustment of grinding speed (860 or 1,720 m/min) according to material type and processing stage.
- Stable base – minimises vibrations and ensures accuracy and operator comfort.
- Large top working surface – ideal for effective deburring and finishing of flat components.
- Easy access to consumables – quick belt and roller replacement minimises downtime.
Design and technology
The CORMAK MS2000 stationary grinder is built for intensive operation. Its heavy-duty steel construction provides rigidity and precision. A 3.3 kW motor drives a grinding belt of 100 × 2000 mm. The integrated dust collection system with two dust containers ensures clean and safe working conditions.
Precision and performance
With adjustable grinding angles between 30° and 90°, the machine enables precise positioning of the workpiece against the belt, essential for grinding welds, joints and edges. The standard grinding roller with a diameter of 42.4 mm ensures versatility – suitable for both thin-walled pipes and square profiles.
Applications
The CORMAK MS2000 belt grinder is used for:
- processing steel, stainless and acid-resistant pipes,
- grinding welds and edges of steel structures,
- finishing surfaces of box sections and flat bars,
- welding, production and locksmith workshops.
Standard equipment
- Stable machine base
- Standard abrasive belt 100 × 2000 mm
- Grinding roller Ø42.4 mm
- Service tools
Technical data
| Grinding diameter |
20 – 76.1 mm |
| Angle adjustment |
30° – 90° |
| Belt speeds |
860 / 1720 m/min |
| Motor power |
3.3 kW |
| Belt dimensions |
100 × 2000 mm |
| Machine dimensions |
1340 × 700 × 1210 mm |
| Weight |
159 kg |
Choose the CORMAK MS2000 pipe and profile belt grinding machine and improve metal processing efficiency in your workshop. Visit CORMAK for details or to order online.
