copy of LUFT 1000 Compressor Set - 7.5kW - 750 L/min. + IZBERG N10S dehumidifier + 270 L vertical cylinder
The set includes the LUFT 1000 screw compressor , a vertical cylinder with compressed air accessories with a capacity of 270 l and the IZBERG N10S dryer. The LUFT series screw compressor of the Polish brand CORMAK is the most modern solutions used in pneumatics combined with the use of high-quality materials and components. Low operating costs, ease of use, ergonomic and solid construction and high efficiency of the device guarantee effective and trouble-free operation.
access_time
Shipping time:
7 working days after receipt of payment
Instructions in Polish
Service
Warranty 12/24 months
Delivery Free
The most important advantages
strong, compact design of a screw compressor from a European manufacturer
automation based on modern and quality-tested components to ensure safe and effective work
a specially designed cooler ensures optimal operating conditions even when the device is heavily loaded
connection of the radiator to the module through good quality hydraulic lines
the technology used allows for significant energy savings
special air outlet design for more effective work
an efficient and solid pump is installed in the compressor
a unique filtration system with three-fold separation to ensure effective operation
The compressor uses a reliable and reliable drive transmission system using a belt transmission, which ensures high effective efficiency
low noise of the screw compressor thanks to a specially designed soundproof housing (sound-insulating boards)
electronic control from the MAM series allows you to set parameters, including: periods between service inspections, power failure alarms, phase direction changes, phase loss, overheating, others, operation in Master/Slave mode, ability to connect up to 16 devices in a pneumatic network, possibility of remote control using a computer and others
Technical parameters of LUFT 1000
Engine power
7.5 kW
Tension
400V/50Hz
Dimensions
810 x 610 x 850 mm
Weight
120 kg
Efficiency
0-6 bar - average 790 L/min At 6 bar - 750 L/min At 8 bar - 750 L/min At 10 bar - 730 L/min
Outlet diameter (G)
1/2"
Technical parameters of N10S
AIR OUTLET AND INLET PIPE DIAMETER (BSP)
1"
WORK IN PRESSURE SYSTEMS
UP TO 10 BAR
INLET TEMPERATURE
≤38°C
DEW POINT TEMPERATURE
3°C at operating overpressure
EFFICIENCY
1500 l/min
POWER
0.58 kW
TENSION
230V
DIMENSIONS (L x W x H)
380x600x625 mm
WEIGHT
31kg
TYPE AND QUANTITY OF COOLING AGENT
R134a, 400 g
270l tank parameters:
Weight (kg)
97
Connections
4
Connection size
1.1/4",1/2",2"
Size
182.5x50 cm
Tank capacity (l)
270
Working pressure (bar)
11
Wall Thickness(mm)
4
Diameter (mm)
Ø 500
Height (mm)
1825
Tank accessories:
1 ½” cork
Pressure gauge + reduction to 1/2 |
½" Tee
½" safety valve
Input-Output 1/1.4-3/4”
½” water drain valve
Quick connector for ½” hose
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI street Brzeska 120, 08-110 Siedlce, Poland
The set includes the LUFT 1000 screw compressor , a vertical cylinder with compressed air accessories with a capacity of 270 l and the IZBERG N10S dryer. The LUFT series screw compressor of the Polish brand CORMAK is the most modern solutions used in pneumatics combined with the use of high-quality materials and components. Low operating costs, ease of use, ergonomic and solid construction and high efficiency of the device guarantee effective and trouble-free operation.
