Semi-Electric Pallet Stacker CORMAK B1040 1000kg 4000mm

Semi-Electric Pallet Stacker B1040 – precise storage at a height of 4 m, reliability and maintenance-free operation

Semi-electric pallet stacker B1040 is a specialised device for transporting and storing loads at height, combining a 1,000 kg load capacity, a 4,000 mm lifting height and advanced safety and power control systems. Thanks to the use of a double-mast column, robust steel construction and a maintenance-free AGM battery 12V 135 Ah, the B1040 model performs exceptionally well in intensive warehouse applications, ensuring precise, efficient and safe pallet handling in narrow working aisles.

Key advantages of the machine

• 1,000 kg load capacity – efficient handling of standard pallets in high-intensity working environments.
• 4,000 mm lifting height – effective use of vertical space in high-bay racking systems.
• Maintenance-free AGM battery 12V 135 Ah – no electrolyte topping-up required, sealed and safe design.
• Battery control system – prevents deep discharge, monitors battery condition and optimises working cycles.
• Precise steering system – enables smooth manoeuvring even in very confined spaces.
• Electromagnetic brake and emergency stop switch – ensures safe operation on inclines and in emergency situations.

Design and technology

The B1040 pallet stacker has been engineered with a strong focus on durability, ergonomics and operational safety. The steel mast structure offers high resistance to deformation and excellent stability at maximum lift height. Forks with a length of 1,150 mm and an outer width of 550 mm ensure compatibility with Euro pallets and easy load handling. The use of polyurethane wheels minimises vibration, reduces noise and protects warehouse floors from damage.

Thanks to its compact dimensions – an overall width of 740 mm and an overall length of 1,735 mm – the stacker is perfectly suited for narrow aisles. A turning radius of 1,430 mm and a low-profile ground clearance of 30 mm facilitate manoeuvring and maintain stability even under maximum load.

Precision and work efficiency

The B1040 stacker delivers excellent performance in terms of lifting and lowering speeds: 100/120 mm/s when lifting and 120/100 mm/s when lowering loads. These parameters enable smooth and controlled work cycles without time losses. The integrated power controller supervises the battery condition, protecting it against overload and enabling optimal charging management.

The stacker is also equipped with a safety cut-off switch that ensures immediate stopping in emergency situations, as well as an electromagnetic braking system that increases operational stability on slopes and loading ramps.

Applications

The B1040 pallet stacker is suitable for professional environments such as:

• high-bay warehouses,
• logistics centres,
• production and distribution departments,
• cold stores and industrial halls,
• order picking and loading areas.

Its design allows safe operation even in demanding working conditions where precision, time efficiency and safety are essential.

Standard equipment

• AGM battery 12V 135 Ah
• Battery charge level indicator
• Polyurethane wheels – low rolling resistance, quiet operation
• Electromagnetic braking system
• Power control system with discharge protection
• Safety cut-off switch

Technical specifications

Increase the efficiency of your storage operations with the semi-electric pallet stacker CORMAK B1040 – enquire about availability and purchasing terms today!
