Electric Pallet Stacker Q10E25 – A Professional Solution for Warehousing and Logistics
The CORMAK Q10E25 electric pallet stacker is a reliable and advanced machine designed for efficient load lifting and transportation. Thanks to its innovative electric drive, it is an ideal choice for companies requiring dependable and eco-friendly equipment for use in confined spaces, warehouses, production halls, and distribution centres. Its compact construction combined with high lifting performance makes the Q10E25 an excellent option for daily warehouse and logistics operations.
Main Features of the CORMAK Q10E25 Electric Pallet Stacker
- High lifting capacity and precision – 1000kg load capacity and 2500mm maximum lift height allow for efficient handling of medium-sized loads.
- Advanced electric drive system – ensures smooth performance while eliminating emissions, making the truck environmentally friendly.
- Ease of operation and safety – equipped with a safety switch and speed controller for operator comfort and security under all working conditions.
- Flexible manoeuvring – the “turtle mode” enables slow, precise movement in tight spaces, perfect for complex tasks in narrow warehouse aisles.
- Maintenance-free AGM battery – long runtime per charge and easy recharging with a built-in charger.
Technology of the CORMAK Q10E25 Electric Pallet Stacker
The Q10E25 pallet stacker combines high efficiency with maximum safety. Its maintenance-free brushless electric motor provides quiet and efficient operation. The use of top-quality components, including a reinforced steel frame, guarantees rigidity and stability during lifting and transport. The stacker is also equipped with a battery charge monitoring system and a belly safety switch, which protects the operator against accidental movement of the truck.
Applications of the CORMAK Q10E25 Electric Pallet Stacker
The Q10E25 electric pallet stacker is perfect for all warehouse, logistics, and production tasks. Thanks to its compact design, it performs exceptionally well in narrow aisles and low-height areas, such as warehouses, distribution centres, or production halls. Its versatility, safety, and user-friendly operation make it an indispensable tool for daily operations requiring precise lifting and handling of loads up to 1000kg.
Standard Equipment of the CORMAK Q10E25
- Maintenance-free brushless electric motor
- Safety switch
- Speed controller
- Built-in charger
- Sealed AGM battery
- LED battery charge indicator
- Belly-type emergency safety switch
- “Turtle mode” for precision manoeuvring in restricted areas
Technical Parameters
| MAX LIFTING HEIGHT |
2500mm |
| LOAD CAPACITY |
1000kg |
| LOAD CENTRE |
600mm |
| FORK LENGTH |
1150mm |
| OUTER FORK WIDTH |
550mm |
| LOWERED MAST HEIGHT |
1830mm |
| EXTENDED MAST HEIGHT |
3050mm |
| LOWERED FORK HEIGHT |
85mm |
| OVERALL WIDTH |
790mm |
| OVERALL LENGTH |
1800mm |
| GROUND CLEARANCE |
30mm |
| TURNING RADIUS |
1390mm |
| TRAVEL SPEED (LOADED / UNLOADED) |
3.5 / 4.0 km/h |
| LIFT SPEED (LOADED / UNLOADED) |
100 / 200 mm/s |
| LOWERING SPEED (LOADED / UNLOADED) |
120 / 100 mm/s |
| GRADEABILITY (LOADED / UNLOADED) |
3 / 10% |
| BRAKE TYPE |
Electromagnetic |
| DRIVE MOTOR POWER |
0.75kW |
| LIFT MOTOR POWER |
2kW |
| BATTERY VOLTAGE / CAPACITY |
12V 75Ah (2 pcs) |
| WHEEL MATERIAL |
Polyurethane |
| WEIGHT |
440kg |
