Why Choose It?
- Water table – eliminates the need for fume and exhaust extraction systems
- Compact dimensions allow installation in almost any workshop
- Voltage height controller THC
- Precise torch positioning
- Highly accurate cutting with no need for additional processing
- Sheet detection system
- Convenient operator console
- Intuitive machine operation
- Capability for cutting and gouging steel
- Machine operation training at the customer’s or seller’s location – arranged individually
- Library of standard geometric shapes
Features and Equipment
- Dimensions 1850×3800×1500 mm (W×D×H), weight – 1000 kg
- Working area 1500 × 3000 mm
- Y-axis range 140 mm (clearance)
- Cutting speed 50–7000 mm/min
- Rigid and stable frame design
- Water table
- Voltage height controller
- Torch height adjustment system
- Torch height and stabilisation sensor
- FastCAM software – licensed version
- USB port and internal/external memory
- User-friendly interface – simple to use even for operators unfamiliar with FastCAM
- Import of *.txt drawings from any CAD software (e.g. AutoCAD, SolidWorks, etc.)
- MACRO – built-in library of standard geometric shapes allowing quick creation without drawing
- NESTING – automatic layout of parts on the sheet
- DEMO – shows the cutting cycle (path) without activating the plasma or oxygen source
Technical Parameters of SPARTUS® ProCUT 125CNC Power Source
| Supply voltage |
~3 × 400V ± 10% 50 / 60 Hz |
| Cutting current [A] |
20 – 100 |
| Max. cutting thickness [mm] |
55 |
| Duty cycle [%] |
100 |
| PLASMA PARAMETERS |
| Output voltage [V] |
88 – 106 |
| Recommended working pressure [bar] |
5.5 |
| Air consumption [L/min] |
250 |
| Post-gas |
YES |
| Non-contact arc ignition without HF |
YES |
| 2T / 4T |
YES |
| OTHER PARAMETERS |
| Current consumption [A] |
28 |
| Power factor (cosφ) |
0.76 |
| Efficiency η [%] |
85 |
| Insulation class |
H |
| Protection class |
IP21S |
| Weight [kg] |
32 |
| Dimensions [mm] |
770 × 270 × 490 |
The plotter is prepared for transport with moving components secured and overall dimensions reduced. Assembly of movable elements and protective covers exposed to transport damage is required. We offer the option of delivering the machine fully assembled — arranged individually due to its dimensions.
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
Brzeska 120, 08-110 Siedlce, Poland
