Vertical Bandsaw CORMAK HBS450N with Laser Indicator

Vertical Bandsaw CORMAK HBS450N with Laser Indicator – precise wood and metal cutting for professional applications

The Vertical Bandsaw CORMAK HBS450N is a durable and reliable industrial bandsaw designed for accurate and efficient cutting of various materials – from non-ferrous metals and aluminium to plastics and wood. Its wide adjustment range, precision-ground cast iron table and laser indicator make it suitable for even the most demanding operators. This bandsaw is an excellent choice for metalworking shops, prototype departments, tool workshops and maintenance sections.

Main advantages of the machine

• Laser indicator – simplifies cutting along the line, improving accuracy and workflow efficiency.
• Quick-release blade tension lever – enables rapid blade replacement without re-tensioning adjustments.
• Precision cast iron table – provides rigidity and can be tilted between -10° and +45°.
• Blade tension window – offers a clear view for monitoring cutting parameters.
• Two-speed blade control – adjustable speed (7 or 14 m/s) ensures optimal performance for different materials.
• Large cutting capacity – cutting height up to 280 mm and width up to 465 mm for large components.

Design and technology

The HBS450N model is constructed on a stable steel frame with a heavy, vibration-damping cast iron table. The bandsaw features drive wheels with a diameter of 480 mm, ensuring smooth blade movement and long component life. The integrated dust extraction system with dual 100 mm outlets helps maintain cleanliness, especially when cutting wood or composite materials.

The drive system is powered by a three-phase motor rated at 2.2kW (S1) with a peak power of 3.1kW (S6). The pulley mechanism allows smooth speed adjustment depending on material and operational needs.

Precision and efficiency

The CORMAK HBS450N Bandsaw provides clean and accurate edges even when cutting demanding materials, thanks to stable tensioning, solid construction and precise table adjustment. The laser indicator reduces setup time and alignment errors, increasing work efficiency.

Applications

The machine is intended for professional use in:

• cutting non-ferrous metals, structural and stainless steel,
• cutting plastics and composite materials,
• tool and prototype production,
• metal workshops, mechanical workshops, technical schools and laboratories.

Standard equipment

• High-voltage safety switch
• Dust extraction outlets 2×100 mm
• Precision fence
• Cutting blade 3605×20 mm, 8 TPI

Optional equipment*

• 100 mm extraction hose
• Zinc-plated clamp
• Mobile base (up to 260 kg)

*The price quoted refers to the machine only, excluding optional/additional accessories, installation, transport and training — please contact our consultant for details.

Technical data

Looking for a dependable bandsaw for precision work? The CORMAK HBS450N is a trusted professional solution. Contact us to learn more about the offer and model availability.
