CNC Milling Machine CORMAK MILL 1500++ – advanced precision and performance in metalworking

CNC Milling Machine CORMAK MILL 1500++ is an advanced CNC machine designed for precise metalworking in demanding industrial environments. With its massive structure, modern CNC control, and large working area, this metalworking centre offers reliability, high performance, and flexibility.

Main advantages of the CNC Milling Machine CORMAK MILL 1500++

CNC Milling Machine CORMAK MILL 1500++ combines a robust construction with advanced technology, providing users with significant advantages in production processes. Key benefits include:

• Large working area: A table measuring 2100x500 mm with a maximum load capacity of 2000 kg and travel range of 1500x550 mm allows machining of large parts, ideal for medium and large production facilities.
• High precision: Positioning accuracy of ±0.04 mm and repeatability of 0.02 mm guarantee excellent surface quality, even for complex geometries.
• Powerful spindle: Spindle speed range of 35–1345 rpm with ISO50 taper and a 7.5 kW motor enables efficient machining of hard materials such as steel, aluminium, and titanium alloys.
• Exceptional stability: Weighing 7300 kg, the heavy cast body minimises vibrations, ensuring stability during intensive cutting operations.
• Feed dynamics: Rapid feed speeds of 6000/6000/3000 m/min and a feed motor power of 2.5 kW ensure high dynamic performance and reduced cycle times.
• Flexible configuration: Options such as Fanuc control, chip conveyor, or full enclosure expand versatility, adapting the machine to specific production needs.
• Intuitive operation: Siemens Sinumerik 808D control with a simple interface and dedicated keyboard streamlines programming and operation, speeding up production.
• Energy efficiency: Dimensions of 3650x2380x2760 mm and an efficient 7.5 kW motor reduce energy consumption and operating costs.
• Wide application range: Capable of machining various materials in one production cycle—from light metals to high-hardness alloys.
• Advanced cooling system: A 550 W coolant pump ensures effective heat dissipation, extending tool life and improving machining quality.

CNC Machining Centre CORMAK MILL 1500++ is an ideal solution for production plants seeking a reliable, precise, and efficient CNC milling machine for a wide range of applications.

Design and technology of the CNC Milling Machine CORMAK MILL 1500++

CNC Milling Machine CORMAK MILL 1500++ has been designed with durability, precision, and ease of use in mind. Key components include:

Construction and worktable

The massive cast-iron frame ensures rigidity and excellent vibration damping. The 2100x500 mm worktable with a maximum load of 2000 kg provides stable clamping for large parts.

Spindle and drive

The ISO50 spindle with a speed range of 35–1345 rpm powered by a 7.5 kW motor delivers excellent cutting performance. The optional chip conveyor increases efficiency and maintains workplace cleanliness.

Guides and drives

Linear guides and powerful servo actuators with a 2.5 kW feed motor ensure smooth movement in X and Y axes (1500x550 mm travel) with rapid feed speeds of 6000/6000/3000 m/min, minimising positioning errors and maximising dynamics.

Control system

Standard Siemens Sinumerik 808D control (optional Fanuc) allows precise programming and process optimisation. The compact IP65-rated control panel ensures reliability in workshop environments, and CAD/CAM integration allows easy adaptation for complex projects.

Precision and performance

CNC Milling Machine for Metal CORMAK MILL 1500++ delivers exceptional accuracy thanks to advanced CNC control and a heavy-duty design. Positioning accuracy of ±0.04 mm and repeatability of 0.02 mm, combined with rapid feed speeds of 6000/6000/3000 m/min, allow for optimised tool paths, reducing cycle times and increasing production efficiency. The powerful 7.5 kW spindle motor and 550 W coolant system make this machine ideal for both batch and single-part production.

Applications of the CNC Milling Machine CORMAK MILL 1500++

Metalworking Centre CORMAK MILL 1500++ is suitable for demanding industries such as:

• Automotive industry: Production of precision components including engine, gearbox, and casing parts.
• Machinery industry: Machining of mechanical components such as shafts, bodies, and structural elements.
• Mould and die manufacturing: Production of injection moulds and dies for automotive and plastics industries.
• Aerospace industry: Machining of aluminium, titanium, and stainless-steel components requiring high accuracy.
• Production workshops: Realisation of single and serial orders requiring flexibility and precision.

With a large working area and flexible configuration options, this CNC machining centre is an excellent choice for medium and large-scale production facilities.

CNC Controls – Siemens Sinumerik 808D and Fanuc

CNC Milling Machine CORMAK MILL 1500++ is available with professional CNC systems from leading manufacturers such as Siemens and Fanuc, offering reliability, precision, and ease of use.

Siemens Sinumerik 808D – advanced control for standard applications

Sinumerik 808D is a compact CNC control system for metalworking machines, providing:

• Intuitive interface: Dedicated keyboard and simple graphic display simplify programming and operation.
• High reliability: IP65 protection ensures stable performance in workshop conditions.
• Advanced functionality: Supports machining cycles and integration with CAD/CAM software.

Fanuc – stability and precision

Fanuc is an optional CNC control for CNC machine tools, providing:

• Operational stability: Ensures precision during long-term, continuous production.
• Advanced functions: Supports complex machining operations.
• User-friendly interface: Enables fast programming and simple operation.

Choose the CNC control system that best suits your needs to improve productivity and machining precision!

Technical parameters

Standard equipment

• RS-232 interface
• Coolant and pump
• Automatic central lubrication system
• Service tools
• User manual
• CE certification

Optional equipment*

• CNC Fanuc control
• Chip conveyor

*The quoted price refers to the machine only and excludes optional or additional equipment, installation, transport and training — please contact our consultant for more details.

Why choose CORMAK?

As an experienced CNC machine manufacturer, CORMAK has been providing reliable industrial solutions for over 20 years. Our CNC machine tools meet the highest quality standards, hold European safety certifications, and are supported by professional service. With an extensive warehouse base (over 15,000 m²) and a team of specialists, we offer comprehensive technical support and consultancy.

• Experience: 16 years of servicing Siemens CNC controls.
• Quality: Machines comply with European safety standards.
• Support: Professional advice and fast warranty and post-warranty service.

By choosing horizontal machining centres from CORMAK, you invest in precision, reliability, and long-term efficiency of your production.

Order your CNC Milling Machine CORMAK MILL 1500++ today!

Increase your production efficiency and machining precision with the CNC Milling Machine CORMAK MILL 1500++. Contact our team for detailed information, a customised quotation, or to arrange a machine presentation.
