Planer Thicknesser CORMAK PT310ECO with Cutterhead – precision and efficient woodworking
The CORMAK PT310ECO is a modern planer thicknesser engineered for high-quality finishing, reliability and low noise operation. Thanks to its cutterhead system, this advanced woodworking machine combines the functions of a surface planer and thicknesser in one solid design. The rigid cast-iron frame and powerful motor make it a versatile solution for professional wood machining – ideal for carpentry workshops and craft facilities.
Main features
- Three-knife cutterhead – fitted with HSS knives 310 × 25 × 3 mm for long life, accurate planing and reduced noise levels.
- Heavy-duty cast-iron tables – absorb vibration and ensure smooth, stable material feed.
- High power output – 2.2 kW (S1) / 2.6 kW (S6) motor delivers consistent performance even under continuous load.
- Large working area – planing width of 310 mm and height up to 180 mm allow machining of a wide range of workpieces.
- Efficient chip extraction – Ø100 mm port enables effective connection to a dust extraction system.
Construction and technology
The PT310ECO features a cutterhead with a 75 mm diameter for smooth operation and improved durability compared to standard knife systems. The planer and thicknesser tables are made of cast iron, measuring 1290 × 310 mm (planer) and 540 × 310 mm (thicknesser), ensuring long-lasting precision and wear resistance. The fence is adjustable from 90° to 45°, allowing accurate bevel planing and angled work.
Precision and performance
The machine achieves a maximum cutting depth of 3 mm in planer mode and 4 mm in thicknesser mode. With a cutterhead speed of 5500 rpm and a stable cast-iron design, it delivers a surface finish ready for gluing, varnishing or further processing. This wood thicknesser is a dependable tool suitable for both serial production and smaller-scale projects.
Applications
The PT310ECO planer thicknesser is ideal for:
- professional carpentry and furniture workshops,
- prototype and training facilities,
- maintenance departments in industrial plants,
- technical schools and vocational colleges.
Standard equipment
- Three-knife cutterhead
- Cast-iron working tables
- Cutterhead guard
- Dust extraction port Ø100 mm
- Feed switch and emergency stop button
Optional equipment
- Mobile transport trolley
- Chip extractor
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
Technical data
| Planer table size |
1290 × 310 mm |
| Thicknesser table size |
540 × 310 mm |
| Cutterhead diameter |
75 mm |
| Cutterhead speed |
5500 rpm |
| Number / size of knives |
3 / 310 × 25 × 2.5 mm |
| Fence tilt angle |
90–45° |
| Chip extraction port |
100 mm |
| Maximum thicknessing height |
180 mm |
| Maximum cutting depth |
3 mm (planer) / 4 mm (thicknesser) |
| Motor power (S1/S6) |
S1: 2.2 kW / S6: 2.6 kW |
| Maximum workpiece width |
310 mm |
| Weight (gross) |
200 kg |
Choose efficiency and durability. Select the CORMAK PT310ECO planer thicknesser with cutterhead and bring top-quality wood machining to your production. Contact our technical consultant today.
