CNC Lathe CORMAK CK7135A with Slant Bed – Precision and Efficiency in Metalworking

The CORMAK CK7135A CNC Lathe with a slant bed is an advanced numerically controlled machine designed for precise metal processing in industrial environments. Equipped with Siemens Sinumerik 808D control and HIWIN linear guides, it ensures high repeatability, performance, and reliability in both serial and single-part production.

Main Advantages of the CNC Lathe CK7135A

The CK7135A CNC Lathe is a solution dedicated to professional manufacturing plants requiring precise and efficient equipment for machining medium-sized components. The machine combines advanced cutting technology, a robust structure, and intuitive CNC control, providing users with exceptional accuracy, durability, and flexibility. Equipped with a turret-type tool holder, Siemens servo drives, HIWIN linear guides, and a hydraulic chuck, it allows for a wide range of machining operations while maintaining the highest quality standards. Thanks to innovative elements such as ball bearings and telescopic guide covers, the machine achieves a positioning repeatability of 0.006 mm, placing it among the leaders in its class. Below are the key benefits of using this machine:

• Exceptional machining precision: Positioning repeatability of the X/Z axes at 0.006 mm ensures excellent component quality, exceeding standard CNC lathes with an accuracy of 0.01 mm.
• High productivity: The turret-type tool holder shortens machining time by up to 25%, eliminating the need for safe retraction movements, thereby increasing production efficiency.
• Versatile applications: A maximum turning diameter of 400 mm and a centre distance of 400 mm allow machining of a variety of parts, from small to medium-sized components.
• Smooth tool movements: Siemens servo drives guarantee precise and dynamic feed movements, minimising errors and improving surface finish quality.
• Intuitive operation: The Siemens Sinumerik 808D control system offers a simple graphical interface, quick programming, and compatibility with CAD/CAM systems, facilitating integration with modern production processes.
• Durable design: The 45° slant bed and HIWIN linear guides ensure high rigidity, minimising vibrations and providing stability during intensive machining.
• Operational cost efficiency: The automatic lubrication system, cooling circuit, and telescopic guide covers reduce maintenance costs, extending the service life of key components.
• Safety and operator comfort: 24V halogen lighting enhances workspace visibility, while the fully enclosed design compliant with CE standards ensures operator safety.
• Configuration flexibility: Options such as Siemens Sinumerik 828D, Fanuc, or GSK control systems, as well as accessories like bar feeders or chip conveyors, allow the machine to be tailored to specific production requirements.
• Process optimisation: The 3-jaw hydraulic chuck and complete set of soft jaws increase clamping flexibility and reduce setup time.

Construction and Technology of the Industrial Lathe

The CORMAK CK7135A CNC metal lathe has been designed with reliability and precision in mind for demanding industrial environments. The use of high-quality components such as Siemens drives and HIWIN linear guides guarantees stable performance and a long machine lifespan.

Slant Bed Construction

The 45° slant bed and HIWIN linear guides ensure outstanding rigidity, minimising vibrations during machining. Telescopic covers protect the guides from contamination, increasing durability and reliability.

Spindle and Drive

The spindle, with a through-hole of 56 mm and a 5.5 kW motor, allows for efficient machining of various shapes and materials within a spindle speed range of 200–3500 rpm, ensuring excellent surface finish quality.

Tool Turret

The turret-type tool holder with 6, 8, or 12 tool positions (depending on configuration) eliminates unnecessary movements, shortens machining cycles, and increases productivity.

Control System

The lathe is equipped with Siemens Sinumerik 808D control, providing an intuitive interface, rapid programming, and CAD/CAM compatibility that streamlines integration with modern production processes.

Cooling and Lubrication System

The integrated cooling system maintains optimal tool and workpiece temperatures, while the automatic lubrication system for gears and guides minimises component wear and reduces operating costs.

Precision and Efficiency

The CORMAK CK7135A Industrial CNC Lathe guarantees exceptional precision with a positioning repeatability of 0.006 mm. Advanced Siemens servo drives, a 3-jaw hydraulic chuck, and a turret-type tool holder ensure stability and repeatability of machining. The high spindle speed (200–3500 rpm) and the ability to configure the tool holder for 6, 8 or 12 tools allow for the execution of complex operations such as threading, grooving, and drilling with the highest surface quality.

Applications of the CNC Metal Lathe

CNC metal lathes like the CK7135A are widely used across various industries, including:

• Automotive industry: Production of precision components such as shafts, sleeves, and drive system elements.
• Machinery industry: Manufacturing of machine parts, tools, and injection moulds requiring high precision.
• Electronics industry: Machining of light alloys and metals used in electronic components.
• Serial and prototype production: Designed for small and medium production runs and prototype projects, particularly for machining medium-sized components.

The machine is an excellent choice for workshops and production plants requiring a compact yet efficient solution for precise metal machining.

Standard Equipment

• SINUMERIK 808D control system
• Siemens servo drives
• 3-jaw hydraulic chuck
• Turret-type tool holder
• Complete set of soft jaws
• HIWIN linear guides
• Telescopic guide covers
• Cooling system
• Automatic lubrication system for gears and guides
• 24V halogen lighting
• User manual
• CE certification

Optional Equipment*

• Sinumerik 828D, Fanuc, GSK control systems
• Tool probe
• Chip conveyor
• Additional soft jaws
• Hard jaws
• Collet chucks
• Finished-part gripper
• Bar feeder
• Tool holders
• CAD/CAM software

*The price applies to the machine only, excluding optional or additional accessories, installation, transport, and training — please contact our consultant for more details.

Technical Parameters

CNC Control Systems – Siemens Sinumerik 808D, SINUMERIK 828D and Fanuc Oi-TF

We offer professional CNC control systems from renowned brands Siemens and Fanuc, ensuring precision, performance and ease of operation. These solutions are ideal for both smaller workshops and demanding industrial applications.

Siemens Sinumerik 808D – Compact CNC Control for Standard Applications

Siemens Sinumerik 808D is a modern, economical CNC system designed for entry-level lathes and milling machines. Created for small and medium-sized enterprises, it offers:

• Intuitive operation – a simple graphical interface that facilitates programming and machine configuration.
• High reliability – a robust design resistant to demanding workshop conditions.
• Wide compatibility – adapted to machines with basic technological requirements.
• An excellent solution for beginners who wish to start working with a modern CNC control system.

Siemens Sinumerik 828D – Advanced Control for Demanding Applications

Sinumerik 828D is a professional CNC control designed for machines requiring higher precision and productivity. Its key features include:

• High computing power – rapid data processing enabling dynamic and accurate cutting operations.
• Extended technological functions – advanced machining cycles, interpolation and tool-path optimisation features.
• Compact, robust construction – built for continuous operation in heavy-duty industrial environments.
• Easy automation integration – expandable with additional modules and process-control options.
• CAD/CAM compatibility – seamless cooperation with design software and production-management systems.

This makes it an excellent choice for companies seeking powerful and reliable CNC control for complex machining operations.

Fanuc Oi-TF – Stability and Precision in Turning Operations

Fanuc Oi-TF is one of the most popular CNC systems for lathes, valued for its reliability and user-friendly operation. It is widely used in the metalworking industry thanks to:

• Exceptional operating stability – precision and reliability even in long-term serial production.
• Advanced turning functions – supports a variety of cycles including threading, grooving and drilling.
• Intuitive user interface – fast programming and easy control through a clear screen and optimised menus.
• Wide compatibility – suitable for numerous lathe models.
• Process optimisation – enhanced control of machining parameters, saving time and material.

With Fanuc Oi-TF, users achieve consistently stable and precise performance, resulting in higher productivity and machining quality.

Selecting the Right CNC Control is crucial for machining efficiency and accuracy. Siemens Sinumerik 808D is ideal for basic applications, Siemens Sinumerik 828D suits more demanding production, and Fanuc Oi-TF guarantees maximum stability and reliability in turning operations.

Why Choose CORMAK?

With over 20 years of experience in supplying industrial machinery, CORMAK is a recognised leader providing reliable CNC metal lathes. Our machines are trusted by professionals due to:

• 16 years of experience in servicing Siemens CNC controls.
• Extensive machine availability – over 15,000 m² of warehouse space with approximately 12,000 machines in stock.
• Professional service support – offering both warranty and post-warranty service.
• European safety certifications – all machines comply with strict workplace safety standards.

Invest in the CORMAK CK7135A CNC Lathe with slant bed and enhance your production efficiency. Contact us today for detailed information and a personalised offer. Our specialists will help you find the best solution for your business!
