Box-Column Drilling Machine for Metal CORMAK WK80A
The CORMAK WK80A box-column drilling machine is a professional industrial tool designed for precision drilling, reaming, and tapping. Its rigid, heavy-duty cast-iron frame ensures maximum stability, while automatic spindle feed and a wide speed range enable efficient metalworking. Ideal for continuous use in production and maintenance environments.
Are you a member of the VIES group?
To use the VIES group, you must have a VAT number.
VAT included
€19,975.00
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Machine Characteristics
The industrial CORMAK WK80A box-column drilling machine is designed for drilling, spot drilling, tapping and similar operations. It stands out for its high precision, wide speed range, low noise level, easy maintenance, and user-friendly operation. Its solid box-column structure guarantees rigidity and accuracy in demanding production conditions.
- Quick and convenient feed and speed adjustment via ergonomic control lever
- Powerful motor with high torque providing strong feed force and drilling pressure
- Tapping function with automatic spindle reversal and adjustable depth control
- Standard equipment includes automatic spindle feed, tapping capability, and integrated lighting
- Fast feed and rapid return motor for improved efficiency
- Durable, reliable operation ensured by the use of high-quality components
- Rigid box-column design and solid base ensure excellent stability and precision
Technical Data
|
Maximum drilling diameter |
80 mm |
|
Tapping capacity |
M56 |
|
Torque |
800 Nm |
|
Head travel along column |
260 mm |
|
Morse taper |
MK6 |
|
Spindle speed (9 steps) |
40–570 rpm |
|
Feed range |
(6) 0.1–0.78 mm/rev |
|
Feed force |
30,000 N |
|
Distance spindle–column |
375 mm |
|
Maximum distance spindle–table |
810 mm |
|
Spindle travel |
250 mm |
|
Table size / T-slots |
660 × 555 mm / 22 mm |
|
Table travel |
300 mm |
|
Motor power |
5.5 kW |
|
Machine dimensions |
900 × 1,300 × 2,850 mm |
|
Weight |
2,500 kg |
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
Brzeska 120, 08-110 Siedlce, Poland
