Box-Column Drilling Machine for Metal CORMAK WK63
The industrial box-column drilling machine is designed for drilling, countersinking and tapping. The series is characterised by exceptional accuracy, a wide speed range, as well as simple operation and maintenance.
Are you a member of the VIES group?
To use the VIES group, you must have a VAT number.
VAT included
€18,725.00
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Machine characteristics
The industrial box-column drilling machine is commonly used for drilling, countersinking and tapping. It is distinguished by high efficiency and accuracy, low noise level, a wide range of speeds, a centralised control panel, and easy operation and maintenance.
- quick and easy adjustment of feed and speed using a convenient control lever
- powerful motor with high torque, high feed and pressure force
- tapping with automatic spindle reversal and adjustable depth control
- standard equipment includes automatic spindle feed, tapping option, and lighting
- rapid feed and return motor
- reliable operation and long service life ensured by the use of high-quality parts and components
- strong and solid design of the column and base
Technical data
|
MAXIMUM DRILLING DIAMETER |
63 mm |
|
TAPPING |
M48 |
|
TORQUE |
800 Nm |
|
HEAD TRAVEL ALONG COLUMN |
260 mm |
|
MORSE TAPER |
MT5 |
|
SPINDLE SPEED (9 steps) |
40–570 rpm |
|
FEED RANGE |
(6) 0.1–0.78 mm/rev |
|
FEED FORCE |
30,000 N |
|
SPINDLE-TO-COLUMN DISTANCE |
375 mm |
|
MAXIMUM SPINDLE-TO-TABLE DISTANCE |
870 mm |
|
SPINDLE TRAVEL |
250 mm |
|
TABLE SIZE / T-SLOTS |
660 × 555 mm / 22 mm |
|
TABLE TRAVEL |
300 mm |
| MOTOR POWER | 5.5 kW |
| MACHINE DIMENSIONS | 900 × 1300 × 2850 mm |
| WEIGHT | 2500 kg |
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
Brzeska 120, 08-110 Siedlce, Poland
