Technical parameters
| Max. thickness of cut sheet metal (S235) |
up to 8.0 mm |
| Maximum cutting length |
2500 mm |
| Cutting angle |
1.5° |
| Number of strokes per minute |
6-20 |
| Backgauge travel |
600 mm |
| Motor power |
7.5 kW |
| Length |
3200 mm |
| Width |
1700 mm |
| Height |
1900 mm |
| Weight |
6200 kg |
Equipment:
-
Rear backgauge driven by an electric motor (with ball screws)
-
Hydraulic sheet hold-downs along the full cutting length
-
Blade gap adjustment
-
Ball transfer sheet guides on the table
-
Working area lighting
-
Front support arms
-
Mobile foot controller
Rear ramp:
The rear ramp is equipped with ball guides, ensuring smooth and precise movement of the cut parts. As a result, no material fragment remains on the machine, which increases work efficiency and safety.
Control and Functionality:
ESTUN E21S
- Control: Precise setting of the rear backgauge.
- Program memory: Option to save up to 40 programmes, each with a maximum of 25 steps.
- Retraction function: Automatic backgauge return after cutting.
- Parameter saving: One-button saving of settings.
- Data protection: Parameters are retained in the event of a power failure.
Steel hydraulic connections
The use of steel pipes in hydraulic systems instead of flexible rubber hoses significantly increases system tightness and minimises the risk of future leaks. Thanks to their rigidity and resistance to mechanical damage, steel pipes ensure durability and reliability of the hydraulic connections.
Ergonomics
Thanks to the mobile controller and the control unit mounted on a movable arm, the operator gains full freedom of operation throughout the machine's working area. Additional LED lighting and a laser indicator ensure excellent visibility of the processed elements, which translates into precision and working comfort in all conditions.
Safety
With operator and staff safety in mind, our guillotine shears have been equipped with a range of solutions that minimise risk during operation:
- Clear warning markings
- Robust guards protecting the cutting zone
- Rear light curtain
- Easily accessible emergency stop switches
Each machine is supplied with a user manual. In addition, our machines have CE certification, confirming compliance with European safety and quality standards.
SCO – Oil Cooling System
Provided as standard, the system guarantees stable machine operating parameters even during long, continuous use.
SKC – Pressure Control System
The pressure control system guarantees reliable blade performance for many years.
Included with the machine
Telephone consultations with a specialist
You can always count on specialist support.
Terms of cooperation
- 24-month warranty.
- The machine is brand new
- Warranty and post-warranty service provided by the seller
