MILL500 Machining Centre
Variant
MILL500 Machining Centre
MILL400 Machining Centre
MILL540 Machining Centre
MILL 530 900 X 400 machining center
Are you a member of the VIES group?
VAT included
€29,335.50
The lowest price of this product in the last 30 days before the discount was €28,572.78 gross
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Technical data
| Table dimensions | 800×260 mm |
| Spindle taper | BT30 (BT40 optional) |
| X-axis travel | 450 mm |
| Y-axis travel | 320 mm |
| Z-axis travel | 420 mm |
| Spindle taper from table surface distance | 90–470 mm |
| Quick travels | 10/10/8 m/min |
| X/Y/Z axes servomotor torque | 6/6/7.7 Nm |
| Positioning accuracy | ±0.02 mm |
| Positioning repeatability accuracy | ±0.01 mm |
| Spindle speed | 8000 rpm |
| Motor power | 3.7 kW |
| Control system | SINUMERIK 808D |
| Weight | 2100 kg |
| Dimensions | 2100×1800×2200 mm |
Available equipment
- SIEMENS 808D
- Manual chuck
- Tailstock
- SIEMENS servomotors
- 8000 RPM spindle speed range
- 10-tool magazine
- 3-colour alarm indicators
- Lighting
- Hermetic body of the machine
- Automatic lubrication system
- Pneumatic system
Optional equipment
- Siemens 828 / FANUC control systems
- Spindle range of 10000 / 12000 RPM
- Cooling via spindle
- Belt shavings ejector + container
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
