MILL2282 Machining Centre
High quality components used in this machining centre ensure reliable, long-term operation. This machine is efficient in many activities such as milling, drilling, threading and reaming while preserving high accuracy of operation. Every device of this series is equipped with an efficient cooling system, providing optimal machining conditions.
Variant
MILL1200 5 Axes Machining Centre
MILL1470 Machining Centre
MILL1780 Machining Centre
MILL 1470 machining center
Are you a member of the VIES group?
VAT included
€160,392.00
The lowest price of this product in the last 30 days before the discount was €156,221.81 gross
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Description
- Highest quality guides for each and every axis
- 4-truck guide system implemented into the bed of the machine for a heavy load capacity
- Rigid body of the machine with spaced out, tempered and ground rectangular guides
- Hermetic chamber provides work safety
- Maximum precision due to lead screws in 3 axes
Technical data
| A choice of control system | SIEMENS 808 ADVANCED |
| Table dimensions | 2200×820 mm |
| T-slots | 5×22×135 mm |
| Table load capacity | 960 kg |
| X/Y/Z axes | 2000×800×700 mm |
| Distance from spindle to table surface | 200–900 mm |
| Distance from spindle to column | 830 mm |
| Spindle taper | BT50 |
| Spindle speed | 100–8000 rpm |
| Spindle drive | Belt |
| Spindle motor | 11 kW |
| X/Y/Z engine axes | 22/22/22 Nm |
| X/Y/Z ball screws (diameter x stroke) | 40×08/40×08/40×08 mm |
| X/Y/Z quick feed speed | 15/15/12 m/min |
| X/Y/Z incision feed | 8 m/min |
| Magazine capacity | BT50–24 |
| Maximum length of tool | 300 mm |
| Maximum weight of tool | 7.5 kg |
| Power supply | 25 KVA |
| Air pressure | 5–7 kilogram-force/cm2 |
| Positioning accuracy | +/– 0.01 mm |
| Dimension | 5420×2800×2810 mm |
| Weight | 14000 kg |
Manufacturer: Cormak
