POWERMAX 105 Plasma Source for Cutters

POWERMAX 105 Plasma Source for Cutters -
  • POWERMAX 105 Plasma Source for Cutters -
  • POWERMAX 105 Plasma Source for Cutters -

Manual or mechanical plasma system for metal cutting and gouging.

Are you a member of the VIES group?

VAT included
€9,725.00
The lowest price of this product in the last 30 days before the discount was €9,725.00 gross
There are not enough products in stock


  • CE
  • Instructions in Polish
  • Service
  • Warranty 12/24 months
  • Delivery
    Free

Maximum productivity

  • High cutting speed: three times quicker than in fuel-air systems during cutting 12 mm thick soft steel
  • Unparalleled quality of cutting and gouging results in a shorter edge grinding and preparation time

Easy handling during cutting and gouging

  • Smart Sense™ technology automatically sets proper air pressure according to the length of the blowtorch and operating mode
  • Handheld, mechanical and robotised simple blowtorches ensure better elasticity and convenient handling
  • High voltage tolerance improves the efficiency of engine generators and low-voltage lines
  • Improved cover reduces the build up of slag and provides smoother cut of higher quality

Manufactured and tested to endure in the harshest working environment

  • Duramax™ blowtorches were designed with durability and resistance to high temperatures
  • SpringStart™ technology ensures consistency of start-up conditions and improves the durability of the blowtorch
  • Small requirements in regard to maintenance as well as a maximum working time – job done faster

Small operation costs

  • Great durability of consumables results in smaller costs and faster work
  • High energetic efficiency lowers power consumption

Technical data

Output voltage 400 V, 3 phases, 50/60 Hz
Input current at 16.8 kW 400 V, 3 phases 28 A
Output current 30–105 A
Rated output voltage 160 V DC
Work cycle at 40°C

80% at 105 A, 400 V, 3 phases

100% at 94 A, 400 V, 3 phases

Open-circuit voltage (OCV) 292 V DC
Dimensions with handles 592×274×508 mm (length×width×height)
Weight with 7.6 m blowtorch 41 kg
Gas feed Clean, dry oil-free air or nitrogen
Recommended gas flow intake speed / pressure

Cutting: 217 l/min at 5.9 bars

Gouging: 227 l/min at 4.8 bars

Length of the power cord 3 m
Power supply type Inverter — IGBT (Insulated Gate Bipolar Transistor)

The set includes:

  • Powermax 105 plasma cutter
  • T105 plasma handle – 7,6m long
  • Ground wire
  • Manual
  • Starting kit (nozzles and electrodes)

Manufacturer: Cormak

CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
