Main advantages of the CORMAK air dryer
- Advanced refrigeration system — a two-stage cooling process down to the dew point ensures effective separation of moisture and oil particles.
- Stable operation up to 10 bar — suitable for use in standard industrial compressed air systems.
- High efficiency — up to 11,500 L/min, making it a powerful solution for large compressed air installations.
- Energy-saving design — the variable-speed fan system reduces power consumption to only 2.13 kW.
- Automatic condensate drain valve — guarantees reliable condensate discharge without operator supervision.
- Compact dimensions and easy installation — perfect for integration into existing pneumatic systems.
Design and technology
The refrigeration air dryer is engineered for maximum efficiency and durability. Its main components include:
1. Air-to-air heat exchanger
In the first stage, the incoming air passes through a heat exchanger where it is pre-cooled by the colder outgoing air from the evaporator. The counterflow design enhances the energy efficiency of the entire system.
2. Refrigeration evaporator
In the second stage, the compressed air enters the evaporator, where it is cooled to a dew-point temperature of 3 °C. This causes condensation of water vapour and oil mist contained in the air.
3. Condensate separator
After cooling, the air–condensate mixture passes through an efficient separator where condensate is automatically removed from the system.
4. Fan speed control system
The variable-speed fan technology automatically adjusts cooling performance to actual demand, reducing energy consumption and extending the service life of key components.
Precision and performance
Thanks to its refrigeration technology, the CORMAK air dryer effectively removes water and oil, protecting installations against corrosion, actuator failure, and pneumatic tool damage. The constant dew-point temperature ensures consistent air quality and reliable system operation.
Applications
The CORMAK air dryer is suitable for a wide range of industrial applications where air purity and dryness are critical for machine performance and product quality. Typical applications include:
- Mechanical workshops
- Production facilities
- Food industry (with appropriate filtration)
- Electronics manufacturing
- Industrial automation
- Paint booths and finishing systems
- Pneumatic CNC machines
Equipment
- Automatic condensate drain valve
- Integrated water and oil separator
- Variable-speed fan — automatically adjusts to operating conditions
- Electronic control system — ensures stable working parameters
- Compact, durable housing resistant to industrial environments
Technical specifications
| Parameter | Value |
|---|
| Inlet/outlet pipe diameter (BSP) |
2" |
| Maximum working pressure |
10 bar |
| Maximum inlet air temperature |
≤ 38 °C |
| Dew-point temperature |
3 °C |
| Air flow capacity |
11,500 L/min |
| Power consumption |
2.13 kW |
| Power supply voltage |
230 V |
| Dimensions (L × W × H) |
1200 × 650 × 970 mm |
| Weight |
170 kg |
| Refrigerant type and quantity |
R410a, 1300 g |
Choose professional air treatment
By choosing the CORMAK refrigeration air dryer, you invest in the reliability and efficiency of your pneumatic system. This device is an essential component of every professional compressed air installation — especially where high air purity and corrosion protection are required.
Prevent costly downtime caused by moisture — choose the CORMAK air dryer and take full control of your air quality!
Contact us and order a model tailored to your system!
