Main advantages of the CORMAK IZBERG N10S air dryer
- Advanced refrigeration system — a two-stage cooling process down to the dew point ensures effective separation of water and oil particles.
- Stable operation up to 10 bar — perfectly matched for use with CORMAK compressors and standard industrial systems.
- High efficiency — up to 1500 L/min, making it ideal for medium and larger air installations.
- Energy-saving design — the variable-speed fan reduces power consumption to just 0.58 kW.
- Automatic condensate drain valve — guarantees reliable condensate removal without operator intervention.
- Compact and easy to install — suitable for both new and existing pneumatic setups.
- Eco-friendly refrigerant R134a — ensures high efficiency while meeting environmental standards.
Design and technology
The refrigeration air dryer has been designed for maximum efficiency and longevity. Its main structural elements include:
1. Air-to-air heat exchanger
In the first stage, incoming air passes through a heat exchanger, where it is pre-cooled by the colder outgoing air from the evaporator. The counterflow design improves overall energy efficiency through heat recovery.
2. Refrigeration evaporator
In the second stage, compressed air enters the evaporator, where it is cooled to a dew point of 3°C. This causes water vapour and oil particles to condense effectively.
3. Condensate separator
After cooling, the air–condensate mixture passes through a high-efficiency separator that automatically discharges the collected condensate.
4. Fan control system
The variable-speed fan system intelligently adjusts the cooling power according to actual demand, reducing energy use and extending component lifespan.
Precision and performance
Thanks to refrigeration technology, the CORMAK N10S dryer effectively removes moisture and oil, protecting pneumatic systems from corrosion, actuator failure, and tool damage. The constant dew point temperature ensures consistent air quality and system reliability.
Applications
The CORMAK IZBERG N10S air dryer is suitable for a wide range of industrial applications requiring clean, dry air to ensure proper machine performance and product quality. Typical areas of use include:
- Mechanical workshops
- Manufacturing plants
- Food industry (with appropriate filtration)
- Electronics production
- Industrial automation
- Paint booths and finishing systems
- Pneumatic CNC machines
Equipment
- Automatic condensate drain valve
- Integrated water and oil separator
- Variable-speed cooling fan — automatic adjustment to working conditions
- Electronic control system — stable and reliable performance
- Compact, durable housing designed for industrial environments
Technical specifications
| Parameter | Value |
|---|
| Inlet/outlet pipe diameter (BSP) |
1" |
| Maximum working pressure |
10 bar |
| Maximum inlet air temperature |
≤ 38°C |
| Dew point temperature |
3°C |
| Air flow capacity |
1500 L/min |
| Power consumption |
0.58 kW |
| Power supply voltage |
230 V |
| Dimensions (L × W × H) |
380 × 600 × 625 mm |
| Weight |
31 kg |
| Refrigerant type and quantity |
R134a, 400 g |
Professional air treatment for maximum efficiency
By choosing the CORMAK IZBERG N10S refrigeration air dryer, you invest in the stability and performance of your pneumatic system. This dryer is an essential component of any professional compressed air setup — especially where air purity and corrosion protection are critical.
Eliminate moisture-related risks — choose the CORMAK air dryer and take full control of your air quality!
Contact us to order a model suited to your needs!
