Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150

Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150 -
  • Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150 -
  • Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150 -
  • Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150 -
  • Quick-Change Tool Post CORMAK MULTIFIX C Type CD32150 -

Multifix tool posts are used for quick and precise clamping of cutting tools on a lathe. They enable rapid tool changes without having to reset them each time, which significantly speeds up work and improves machining repeatability. The Multifix system also provides stable tool clamping, accurate cutting edge height adjustment and greater operating convenience.

Have questions? Call us!

+48 25 631 00 27 ext.105

Are you a member of the VIES group?
To use the VIES group, you must have a VAT number.

VAT included
€1,322.25

Product available on request. Please contact our sales department.

There are not enough products in stock


  • CE
  • Instructions in Polish
  • Service
  • Warranty 12/24 months
  • Delivery
    Free

The set includes:

✔ body with clamping lever

head 540-200 x 1 pc

✔ tool holders

holder 540-211 x 3 pcs

holder 540-220 x 1 pc

✔ 1 square socket wrench

Features:

✔ Smooth adjustment of the tool tip position to the lathe spindle axis

✔ No spacer shims required

The hole in the centring disc must be bored to diameter R appropriate for the diameter of the carriage clamping screw.

Dimension A Dimension B Tool post type Dimension C C max. Dimension D Dimension E cscsc
Size Aa 18–26 mm up to 12 mm AaD1250 12 mm 12 mm 37 mm 36 mm 50 mm
Size A 30–39 mm up to 20 mm AD2090 20 mm 31 mm 53 mm 56 mm 90 mm
Size B 37–57 mm up to 25 mm BD25120 32 mm 51 mm 79 mm 85 mm 120 mm
Size C 47–87 mm up to 32 mm CD32150 40 mm 70 mm 110 mm 115 mm 150 mm
Size E 28–39 mm up to 20 mm ED20100 20 mm 31 mm 68 mm 70 mm 150 mm

Manufacturer: Cormak

CORMAK JERZY ZALEWSKI
Brzeska 120, 08-110 Siedlce, Poland
