FU1700 CONSOLE MILLING MACHINE
The FU1700 console milling machine is a unique device with a solid construction. Thanks to the use of servo motors and ball screws in all axes, it ensures extraordinary precision and efficiency. Additional amenities such as a universal swivel head, central lubrication and an LED lamp make operation easy and comfortable. This is a tool that will meet even the most demanding tasks.
Variant
FU1600 Knee-and-Column Milling Machine
FU2000 Knee-and-Column Milling Machine
FU1700 CONSOLE MILLING MACHINE
Are you a member of the VIES group?
VAT included
€29,793.68
The lowest price of this product in the last 30 days before the discount was €29,019.04 gross
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Machine Characteristics
- Powerful axis servo motors enable stepless feed changes in all three axes, ensuring precise machining.
- Telescopic covers on the Y-axis protect the feed spindle from contamination and damage.
- The universal milling head tilts in two planes and allows easy change of machining mode from horizontal to vertical.
- Possibility to set almost any head angle thanks to the connection of both tilting planes, which increases the flexibility of processing.
Technical data
|
Table dimensions |
1700x400mm |
|
Table travel (X/Y/Z) |
1300/450/600 mm |
|
Feedrate in the X axis |
25~800mm/min |
|
Feedrate in the Y axis |
25~800mm/min |
|
Feed rate in the Z axis |
8~267mm/min |
|
Spindle taper |
7:24 IS050 (H) 7:24 IS050 (V) |
|
Upper arm movement |
700mm |
|
Distance of the vertical spindle from the table |
200-850mm |
|
Distance of the horizontal spindle axis to the arm surface |
200mm |
| Rotational speed range |
50-1520 (Vertical) rpm. |
|
Number of spindle speed gears |
12/12 |
|
T-slots (number/width/spacing) |
3/18/100mm |
|
Spindle motor power |
5.5 (Horizontal) 7.5 (Vertical) Sq |
|
Feed servo drive torque |
12 Nm |
|
Dimensions |
2245×2100×2000 mm |
|
Weight |
3580 kg |
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
