CNC Aggregate Head CORMAK ISO30/ER25 0–180° B6314B0036
CNC aggregate head ISO30 for routers with automatic tool change (ATC), featuring an ER25 collet spindle with manual tool angle adjustment.
Are you a member of the VIES group?
To use the VIES group, you must have a VAT number.
VAT included
€5,694.00
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
200,00 PLN
Technical data
| Maximum spindle speed | 8,000 – 18,000 rpm |
| Maximum tool speed | 8,000 – 18,000 rpm |
| Speed ratio | 1:1 (IN: OUT) |
| Taper type | ISO 30 |
| Tool shank diameter | Ø1 ÷ Ø16 mm |
| Blade diameter | Ø180 |
| Manual tool angle adjustment | 0–180° |
| Working depth | 50 mm |
| Weight | 4.3 kg |
| Lubrication | Kluber NBU 15 grease |
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
Brzeska 120, 08-110 Siedlce, Poland
