Spindle Moulder CORMAK SH-30S PRECISA 400V is an efficient and precise woodworking machine, designed for professional wood machining in industrial plants, joinery shops and craft workshops. Thanks to its stable construction, interchangeable spindle and wide range of spindle speeds, it delivers the highest standard of work when milling straight elements as well as complex shapes.
Main advantages of the machine
- Stable, cast-iron table construction ensures vibration damping and ideal sliding of the workpiece.
- Spindle speed range: 1400 / 4000 / 6000 / 9000 rpm enables machining of various wood species and wood-based materials.
- Reinforced and balanced spindle ensures quiet and precise operation without vibration.
- Height adjustment with scale allows accurate setting of machining parameters.
- Comprehensive standard equipment included – tilting fence, handles and installation tools.
- Meets all H&S standards, CE certification and CE – ensures safe operation and compliance with regulations.
Design and technology
The construction of the CORMAK SH-30S PRECISA spindle moulder is based on a robust body made of high-grade cast iron, which effectively eliminates unwanted vibrations during operation. The work table measuring 620 x 510 mm has been precisely ground, ensuring smooth and even material feed. The fitted 2.2kW motor (400V) provides adequate power even under intensive use. Thanks to a 100 mm spindle stroke and a maximum clamping height of 105 mm, the machine handles a wide range of milling tasks with ease.
Precision and working efficiency
The CORMAK SH-30S PRECISA spindle moulder combines high build quality with functionality. Multi-step spindle speed adjustment allows optimal matching of parameters to the type of machined material and the cutter shape. Precision guides and stops enable accurate setting of reference points, resulting in repeatability and the quality of the final effect.
Applications
The CORMAK SH-30S PRECISA model is used in:
- professional joinery shops and production plants,
- furniture workshops and craft studios,
- manufacturing decorative mouldings, grooves, tongues, tenons and joints,
- edge machining of straight and curved elements.
Standard equipment
- Tilting fence 60° left/right
- Workpiece holder
- Workpiece stop
- Anti-slip feet
- Installation tools
Optional equipment
Interchangeable spindle with ER20 collet chuck allows quick changeovers and adaptation of the machine to different tools at a price of PLN 700 net
Technical parameters
| Motor power S1 |
2.2kW |
| Voltage |
400 V |
| Table dimensions |
620 x 510 mm |
| Table height |
860 mm |
| Extraction port |
100 mm |
| Spindle stroke |
100 mm |
| Max. clamping height |
105 mm |
| Table opening |
160 mm |
| Max. tool diameter under the table |
150 mm |
| Spindle speed |
1400 / 4000 / 6000 / 9000 rpm |
| Spindle diameter |
30 mm |
| Gross weight |
126 kg |
| Overall dimensions |
640 x 660 x 1250 mm |
Choose reliability and precision – select the CORMAK SH-30S PRECISA 400V spindle moulder and improve the quality of wood machining in your workshop. Contact our technical advisor and discover this machine’s capabilities in practice!
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
