The cyclone attachment with a waste container and suction hose included enables connection of two machines simultaneously. The separation process in the cyclone operates on the principle of centrifugal force, with extracted dust collecting in the container beneath. The efficiency of the separator ranges between 90–95%.
The cyclone must be connected to a fan or dust extractor.
Inside the cyclone, contaminated air enters a cylindrical chamber and begins to rotate, causing heavier particles suspended in the airflow to be pushed outward by centrifugal force. As they rub against the cyclone walls, they lose speed (kinetic energy) and fall under gravity. The lightest dust particles are filtered through the dust cartridge and drop down into the collection bag, while clean air exits through the sides of the filter.
| Container capacity | 118 L |
| Bag size | Ø500 x 850 mm |
| Inlet diameter | 125 mm |
| Inlet adapter diameters | 1 x Ø125 / 2 x Ø100 mm |
| Outlet diameter | 125 mm |
| Outlet adapter diameters | Ø125 mm / Ø100 mm |
| Weight (net/gross) | 24 / 26.5 kg |
| Overall dimensions | 785 x 508 x 1545 mm |
(The fan, extractor and Ø100 mm hose are not included in the set!)
