CORMAK RM-S 3050/200 sheet metal rolling mill

CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill - Roll Bender CORMAK RM-S 1550/150
  • CORMAK RM-S 3050/200 sheet metal rolling mill -
  • CORMAK RM-S 3050/200 sheet metal rolling mill -

The industrial three-roll RM-S3050/200 rolling mill with a motorized side shaft and pre-bending is used for high-quality production of cylindrical forms and conical with different diameters. This model is intended for bending sheet metal up to 5 mm thick and up to 3050 mm wide. The diameter of the upper cylinder is 200 mm. Mechanical rolling mills of theRM-Sseries are an excellent choice for bending the thickest sheets in industrial plants in serial and large-scale production.

>

VAT included
€40,210.22
The price has not changed
There are not enough products in stock


  • CE
  • Instrukcja
    po polsku
  • Serwis
  • Gwarancja
    12/24
    miesięcy
  • Dostawa
    Gratis

Most important advantages:

  • Asymmetrical rolls with certificated quality and high mechanical strenght
  • Asymmetrical position of rolls for pre-bending
  • Rolls powered by a powerful transmission with a gearbox
  • Tiltable upper pressure for simple and fast receipt finished detail
  • The device provide possibility conical bending
  • Standard equipment includes groove mounting wire for upper and down rolls
  • Foot switch for left/right work
  • Upper roll regulated by manual wheel
  • Motorized rear roll
  • Serial equipped fot braking motor
  • Stable and compact construction made for cast iron adapting for the large load
  • Machine made in accordance with the EC Safety Directive (CE mark) / Declaration of Conformity

Technical data

Working length 1550 mm
Shaft diameter 130 mm
Min. bending diameter 225 mm
Max. thickness 5/6 mm
Prebending 4/5 mm
Motor power 2,2 kW
Motor power back roll 1,1 kW
Widht 3250 mm
Depth 650 mm
Height  1020 mm
Weight 1400 kg

Are you interested in this product?

Contact with us

Reviews

Write your review

CORMAK RM-S 3050/200 sheet metal rolling mill

The industrial three-roll RM-S3050/200 rolling mill with a motorized side shaft and pre-bending is used for high-quality production of cylindrical forms and conical with different diameters. This model is intended for bending sheet metal up to 5 mm thick and up to 3050 mm wide. The diameter of the upper cylinder is 200 mm. Mechanical rolling mills of theRM-Sseries are an excellent choice for bending the thickest sheets in industrial plants in serial and large-scale production.

>
