Sheet Metal Rolling Mill CORMAK RM-S 1550/170

Machine description

• The RM-S series - unlike RM - is intended for bending thicker sheets and mass production. These rolling mills have greater power, functionality, efficiency and durability. The standard version of the RM-S series includes an electric motor for regulating the side roller, which allows for pre-bending. Thanks to the increased power of the main and side engines and the reinforced frame structure, it is possible to obtain the smallest diameters of bent parts from the thickest sheets.

• The asymmetric design of the roller system allows for preliminary bending of the sheet metal by moving the side roller. Bending the ends of the sheet metal is an important work function that ensures the quality of the final detail, which allows obtaining a uniform, closed form. To bend in both directions, unfold the sheet and press the side roller twice.

• The upper roller is foldable, which makes it easier to remove finished products. It is equipped with a lock that prevents it from opening spontaneously during operation.



  Processing scheme with pre-bending:



  Key advantages:

• Stable, compact, heavy, steel welded structure adapted to heavier loads.

• Rollers made of steel with increased tensile strength in accordance with the SAE 1050 quality certificate, hardened and ground.

• RM-S series rollers ensure initial bending of sheet metal thanks to the asymmetric arrangement of rollers and a motorized side roller.
• This allows you to bend sheet metal into perfectly round closed forms with a minimum diameter with high quality and repeatability.

• Roller drive via a spiral reducer - provides powerful torque and significantly increases efficiency.

• Modern motor with brake - enables precise bending of steel sheets.

• Central lubrication system - ensures stable and long-lasting operation without interruptions for maintenance.

• The upper cylinder can be detached to the side with a support system.

• Lower roller with height adjustment (manually as standard).

• Rollers equipped with grooves for bending bars.

• The RM-S series allows for conical bending.

• Optional motorized lower roller lifting.

• Optional digital position indication of motorized lower and side rollers.

• Optional rollers for bending pipes and profiles.

• The machine is manufactured in accordance with the EC Safety Directive (CE mark) / Declaration of Conformity.

Technical parametres

NOTE: Standard equipment ratings are based on metals with a cold yield strength of 260 N/mm 2

Optional equipment: Motorized lower shaft (electric motor) Digital side shaft position indicator Digital indicator of the lower shaft position Rollers for bending pipes and profiles on elongated shafts Extended shafts
