C1325 BSP CNC Milling Router Basic without Vacuum pump

Construction

• Welded steel rigid structure,
• The arms of the gate are made of hardened, thick, powder-coated sheet metal, which has increased stiffness, which translates into the quality of the processed detail.

Workbench

• The work table was made in hybrid technology,
• It has T-slots for manual clamping material with dimensions of 1300 x 2500mm,

Drive

• Engines used to drive high-power machine tools provide appropriate acceleration and speed in individual directions.
• The X and Y axes feature high-quality HIWIN toothed racks praised by users, which ensure high durability and precision,
• All axes move on rail guides.
• Machine equipped with tool height sensor
• Linear bearing: trapezoidal rails

Spindle

• High quality spindle that is durable.
• Additionally equipped with an air cooling system
• The construction of the spindle uses high-quality sealed bearings, characterized by very quiet operation and guaranteeing increased durability.
• Tool height measurement sensor - included.
• Spindle speed range is 4,500 to 18,000 rpm.
• Tool clamping with 3 pcs ER32 collets, diameters 1/8", 1/2" and 5-6mm

Software

• The machine is equipped with ARTCAM PRO software as standard
• Optional available: UCANCAM V11 CAD/CAM CNC software in Polish version
• The software enables quick and easy design of elements, which the program then converts into the so-called. G-code. It is also possible to import ready-made files from other programs.

DSP control

• Digital Signal ProcessingDigital Signal Processing
• The DSP controller of the machine has its own processor and operating memory, which ensures trouble-free operation and simple operation of the machine.
• The driver ensures smooth operation of the device and accuracy in machining.
• There is no need to reinitialize the program after a power loss.
• The memory built into the controller allows the machine to work without having to load the program each time.

Technical parameters

ATTENTION!

The machine is equipped with the function of remembering the last track of the G-code. In the event of a power failure or interruption, it restarts from the last point without losing time or material.

*Unloading and placing the machine on the customer's side.
