C2030 ATC PREMIUM CNC 4 Axis Milling Machine

The machining center provides versatility of machining (cutting, drilling, milling, engraving). Free access to the machine allowing operation by one operator. The offered plotter is a precise machine based on components from global manufacturers. Thanks to the technology used, we can define ourselves as one of the leaders on the Polish market. The CORMAK C2030 ATC CNC milling plotter is designed for processing and cutting wooden materials, chipboards, MDF, OSB, plywood, PVC, plexiglass, dibond. SERVO AC YASKAWA motors provide adequate acceleration and speed in individual directions.

The machine is controlled by a JAPANESE (not Chinese) industrial controller with a manipulator and an LCD display

Variant

CNC milling machine C2030 ATC PREMIUM (2100 x 3200) + hybrid table

C2030 ATC CNC 4 AXIS SERVO PROFESSIONAL Milling Machine

C2040 ATC PREMIUM CNC Milling Machine

CNC milling machine 1325 ATC (automatic tool change)

CNC C1530 ATC milling machine (1500x3000) automatic tool change

Have questions? Call us!

+48 25 631 00 27 ext.105

export@cormak.pl

Are you a member of the VIES group?

Yes - show prices with VAT 0%

VAT included

€44,280.00

The lowest price of this product in the last 30 days before the discount was €43,128.72 gross

There are not enough products in stock

I agree to the terms and conditions and the privacy policy

Instructions in Polish
Service
Warranty 12/24 months
Delivery
2 000,00 PLN

Machine description

1. Workbench

The work table was made in hybrid technology,
Has grooves that ALSO enable manual fastening of material with dimensions of 2100 x 3300 mm,
An autopsy table with four independent vacuum sections with a 7.5 kW pump!

2. Table vacuum section adjustment

3. HQD spindle

High-end brushless spindle, which is characterized by a very high power of 9 kW
Additionally equipped with an innovative AIR / non-liquid cooling system!
The construction of the spindle uses high-quality sealed bearings, characterized by very quiet operation and guaranteeing increased durability.
Spindle speed range is 4,500 to 24,000 rpm.
Oil mist can be added for an additional fee

4. 4 sc

versatility of processing (cutting, drilling, milling, engraving)
free access to the machine allowing operation by one operator

5.Vacuum pump

Vacuum pump - 7.5 kW (up to 440 mbar)
4 independent vacuum sections

6. and 7. Drive

SERVO motors used to drive high-power machine tools, ensure appropriate acceleration and speed in individual directions.
The X and Y axes feature high-quality toothed bars praised by users, which ensure high durability and precision,
The Z axis is driven by a high quality ball screw.
All axes move on rail guides.
Machine equipped with tool height sensor
Gate drive on toothed racks, rolling linear guides.
Linear bearings: trapezoidal rails, Hiwin carriages

8. Construction

The construction of the sliding gate is made of a cast iron that achieves incredible stiffness, it absorbs vibrations generated during processing very well.
Rigid table structure, made of high quality materials. During the production process, it is subjected to heat treatment.
Free access to the machine for single operator operation

9. Tool magazine

Tool holder ISO30 collet ER32
Tool magazine 8 items,
Tool height measurement sensor,
The set includes holders: ISO30 and sleeves for mounting tools with dimensions:
-1/2" - 6 pcs.
-1/8" - 2 pcs.
-3-4mm - 2 pcs.
-5-6mm - 4 pcs.
-7-8mm - 2 pcs.
-9-10mm - 2 pcs.
A compressor is required for automatic tool change

Software:

The machine supports the latest version of CAD/CAM software.
Software included in the price of the machine (the software provides the ability to import files from Corel, Autocad, etc. File import/export, text editor and input, and many other functions)
The software enables quick and easy design of elements, which the program then converts into the so-called. G-code. It is also possible to import ready-made files from other programs.

YASKAWA SERVO AC motors (see )

used to drive high-power machine tools, they provide appropriate acceleration and speed in individual directions.

Milling machine on new software.

The machine is controlled by a JAPANESE (not Chinese) industrial controller with a manipulator and an LCD display

Technical parameters

Workspace	2150x3300mm
Z axis	350mm
Construction	Arm - Cast Iron / Table - Welded Steel
Drives	hybrid servo motors
Table	hybrid
Spindle power	9kW
Spindle	HQD air cooled (oil mist optional)
Spindle revolutions	from 6000 to 24000 rpm
Power	400 V, compressed air min. 8 bar
Re-positioning accuracy	0.01mm
Linear bearing	trapezoidal rails, Hiwin carriages
Material attachment	vacuum, hybrid
Pump	vacuum 7.5 kW, 4 independent vacuum sections
Dimensions	4070 x 2870 x 1950mm
Weight	2050 kg

ATTENTION!

The machine is equipped with the function of remembering the last track of the G-code. In the event of a power failure or interruption, it restarts from the last point without losing time or material.

*Unloading and positioning of the machine by the customer.

Equipment

Air-cooled spindle, premium version
Hybrid servo drives
Elevated gate in the Z axis for 350mm
Vacuum table - 4 independent vacuum sections + T-groove table for manual material clamping (handles included)
Vacuum pump 5.5 kW included in the price
Tool measurement sensor included
Software included
Tools, collet set, leveling feet and other accessories
DSP Control - Digital Data Processing
Machine equipped with the function of remembering the last track of the G-code (In the event of a power failure or interruption, it starts working from the last point without losing time and material.)
