PIPE LATHE CORMAK CKT1000x2000 SPINDLE THROUGHPUT 320 MM SIEMENS SINUMERIK
The Cormak lathe is a professional machine designed for precision machining of parts with large diameters and considerable lengths. It is ideal for turning pipes, bushings and other components used in the oil, gas, hydraulic or construction industries.
The machine enables workpieces with a maximum diameter of up to 1,000 mm to be machined and is equipped with a spindle with a passage of 320 mm, which offers great technological possibilities. The double-sided chucking system guarantees stable clamping of even the longest workpieces, allowing high accuracy and safety during work.
Are you a member of the VIES group?
VAT included
€50,983.50
The price has not changed
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Technical parameters
| CENTER DISTANCE | 2000 mm |
| MAXIMUM WORKPIECE TURNING DIAMETER | 1000 mm |
| MAXIMUM TURNING DIAMETER OVER THE BRACKET | 620 mm |
| MAXIMUM ELEMENT LENGTH (IN TURNING BETWEEN THE HOLDER AND CENTER) | 2000 mm |
| SPINDLE BORDER | 320 mm |
| TOOLS | 4 OPTION 6,8 |
| SPINDLE SPEED (2 SPEEDS) | 22-108,60-300 RPM |
| MAXIMUM X/Z AXIS TRAVEL | 1850/620 |
| AXIS ACCELERATED FEED RATE X/Z | 4/8 m/min |
| AXIS REPEATABILITY X/Z | 0.012/0.02; 0.025 mm |
| TAILSTOCK SLEEVE DIAMETER | 100 mm |
| MAXIMUM TAILSTOCK SLEEVE TRAVERSE | 250 mm |
| TAILSTOCK SLEEVE TIP | MT5 |
| MOTOR POWER | 11 kW |
| WEIGHT | 8000 kg |
| DIMENSIONS | 5307 x 2040 x 1855 mm |
Available equipment
- SINUMERIK 808D control in Polish
- 2 x manual 4-jaw lathe chuck 630 mm
- 4-position tool head
- set of jaws
- manual tailstock
- cooling system
- automatic lubrication system for gears and guides
- 24V halogen lighting
- user manual in Polish
- CE declaration of conformity
Optional equipment
- spindle passage 270 mm
- 6 and 8 tool post
- handwheels
- 3-jaw chuck 400 mm
- chuck + hydraulic tailstock
- control: FANUC, , SIEMENS 828D
- steady rest + moving rest
CNC controls – Siemens Sinumerik 808D, SINUMERIK 828D and Fanuc Oi-TF
We offer professional CNC controls from renowned brands Siemens and Fanuc, which provide precision, efficiency and ease of use. Our solutions are ideal for both smaller workshops and demanding industrial applications.
Siemens Sinumerik 808D – compact CNC control for basic applications
Siemens Sinumerik 808D is a modern, economical CNC control dedicated to entry-level lathes and milling machines. The system was designed with small and medium-sized enterprises in mind, offering:
- Intuitive operation – a simple interface based on a graphic screen that makes it easy to program and configure the machine.
- High reliability – a durable design resistant to difficult working conditions in the workshop.
- Wide compatibility – adapted to machines with basic technological requirements.
- A perfect solution for beginner CNC users who want to start working on a modern control system.
Siemens Sinumerik 828D – advanced control for demanding applications
Sinumerik 828D is a professional CNC control designed to work with milling machines and lathes requiring greater precision and efficiency. Its key features include:
- High computing power – fast data processing enables dynamic and accurate machining.
- Extensive technological functions – advanced machining cycles, interpolation and tool path optimization functions.
- Solid, compact design – designed for operation in difficult industrial conditions.
- Easy integration with automation – expandable with additional modules and production process control options.
- Compatibility with CAD/CAM – seamless cooperation with design software and production management systems.
This is an excellent choice for companies looking for efficient and reliable CNC control for more complex machining operations.
Related categories
16 other products in the same category:
This lathe saves the actions of its operator and automatically converts them into G-code. Afterwards, the operator can press the playback button in order to achieve an identical copy of the workpiece. This cuts in half the amount of time required to configure the CNC lathe, and increases efficiency ...More
CNC LATHE CORMAK CKT630X5000 SIEMENS SINUMERIK
Our unique CKT630x5000 CNC Lathe is the perfect solution for both experienced specialists and those starting out in serial and individual production. The series of heavy lathes has been designed with maximum cutting efficiency in mind, ensuring optimal results even with intensive use. Thanks ...More
TUBE LATHE CORMAK CKT800 SPINDLE THROUGHPUT 220 MM SIEMENS SINUMERIK
The Cormak pipe lathe is a reliable and highly efficient solution for machining workpieces with large diameters and considerable lengths. With the ability to turn workpieces up to 800 mm in diameter and a spindle passage of 220 mm, the machine is ideal for machining tubes and bushings used in the ...More
CNC LATHE CORMAK CKT800X5000 SIEMENS SINUMERIK
The CKT800x5000 CNC lathe is an excellent choice for both experienced specialists and those starting out in serial and individual production. The series of heavy lathes has been designed with maximum cutting efficiency in mind, guaranteeing excellent results even with intensive use. ...More
CNC LATHE CORMAK CKT800X4000 SIEMENS SINUMERIK
The CKT800x4000 CNC lathe is a modern machine designed for precise and efficient machining. Solid construction, wide guides and an advanced control system guarantee excellent stability and repeatability of processes. It ensures high quality of work in both serial and individual production, meeting ...More
TUBE LATHE CORMAK CKT800 SPINDLE THROUGHPUT 130 MM SIEMENS SINUMERIK
The Cormak professional tube lathe has been designed for efficient machining of large diameter and long workpieces. The machine offers an impressive turning diameter of up to 800mm and a spindle throughput of 130mm, enabling efficient machining of a wide range of tubes and bushings used in the oil, ...More
TUBE LATHE CORMAK CKT800 SPINDLE THROUGHPUT 270 MM SIEMENS SINUMERIK
The Cormak professional tube lathe has been designed for efficient machining of large diameter and long workpieces. The machine offers an impressive turning diameter of up to 800mm and a spindle throughput of 270mm, enabling efficient machining of a wide range of tubes and bushings used in the oil, ...More
CNC LATHE CORMAK CKT800X5000 SIEMENS SINUMERIK
The CKT800x5000 CNC lathe is a perfect solution for both experienced specialists and those starting out in serial and individual production. Designed with maximum cutting efficiency in mind, it guarantees optimal results even with intensive use. The solid construction and wide guides ...More
CORMAK CKT1000x3000 PIPE TURNING MACHINE 270 MM SIEMENS SINUMERIK
The Cormak professional tube lathe has been designed for efficient machining of large diameter and long workpieces. The machine offers an impressive turning diameter of up to 800mm and a spindle throughput of 270mm, enabling efficient machining of a wide range of tubes and bushings used in the oil, ...More
The lathe remembers the actions performed by the operator and automatically converts them to G-codes. Then the operator presses the playback button to obtain an identical copy of the processed element. It allows to reduce the setup time of the CNC lathe by half and the work efficiency by 62%. ...More
TUBE LATHE CORMAK CKT800 SPINDLE THROUGHPUT 270 MM SIEMENS SINUMERIK
The Cormak professional tube lathe has been designed for efficient machining of large diameter and long workpieces. The machine offers an impressive turning diameter of up to 800mm and a spindle throughput of 270mm, enabling efficient machining of a wide range of tubes and bushings used in the oil, ...More
CNC LATHE CORMAK CKT630X6000 SIEMENS SINUMERIK
Our unique CKT630x6000 CNC Lathe is the perfect solution for both experienced specialists and those starting out in serial and individual production. The series of heavy lathes has been designed with maximum cutting efficiency in mind, ensuring optimal results even with intensive use. Thanks ...More
CORMAK CKT800x3000 PIPE TURNING MACHINE 130 MM SIEMENS SINUMERIK
