Instructions in Polish
-
Service
-
Warranty 12/24 months
-
Delivery
Free
The most important advantages
- strong, compact design of a screw compressor from a European manufacturer
- automation based on modern and quality-tested components to ensure safe and effective work
- a specially designed cooler ensures optimal operating conditions even when the device is heavily loaded
- connection of the radiator to the module through good quality hydraulic lines
- the technology used allows for significant energy savings
- special air outlet design for more efficient work
- an efficient and solid pump is installed in the compressor
- a unique filtration system with three-fold separation to ensure effective operation
- The compressor uses a reliable and reliable drive transmission system using a belt transmission, which ensures high effective efficiency
- low noise of the screw compressor thanks to a specially designed soundproof housing (sound-insulating boards)
- electronic control from the MAM series allows you to set parameters, including: periods between service inspections, power failure alarms, phase direction changes, phase loss, overheating, others, operation in Master/Slave mode, ability to connect up to 16 devices in a pneumatic network, possibility of remote control using a computer and others
Technical parameters of Theor 7.5
| Engine power |
5.5 kW |
| Tension |
400V/50Hz |
| Performance at 0-6 bar |
690 l /min |
| Performance at 6 bar |
650 l/min |
| Performance at 8 bar |
650 l/min |
| Performance at 10 bar |
630 l/min |
| Outlet diameter (G) |
3/4" |
| Dimensions |
770 x 640 x 860 mm |
| Libra |
170 kg
|
Technical parameters of N10S
| AIR OUTLET AND INLET PIPE DIAMETER (BSP) |
1" |
| WORK IN PRESSURE SYSTEMS |
UP TO 10 BAR |
| INLET TEMPERATURE |
≤38°C |
| DEW POINT TEMPERATURE |
3°C at operating overpressure |
| EFFICIENCY |
1500 l/min |
| POWER |
0.58 kW |
| TENSION |
230V |
| DIMENSIONS (L x W x H) |
380x600x625mm |
| LIBRA |
31kg |
| TYPE AND QUANTITY OF COOLING AGENT |
R134a, 400 g |
500l tank parameters:
| Weight (kg): |
145.00 |
| Connections: |
8 |
| Connection Size: |
1/2", 2" |
| Size: |
209.8 x 60cm |
| Tank capacity (l): |
500 |
| Working pressure (bar): |
11 |
| Diameter (mm): |
Ø 600 |
| Height(mm): |
2100 |
Tank accessories:
- 1 ½” cork
- Pressure gauge + reduction to 1/2 |
- ½" Tee
- ½" safety valve
- Input-Output 1/1.4-3/4”
- ½” water drain valve
- Quick connector for ½” hose
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
