80x68 mm Machine Vice
Our offer includes a wide range of machine vices: angle, precision and grinding. All of them are made of high-quality materials, providing durability and versatility.
-
Instrukcja
po polsku - Serwis
-
Gwarancja
12/24
miesięcy -
Dostawa
Gratis
Vice features
-
Cast iron rotary QH machine vice, useful while working with grinding, milling, drilling and planing machines, etc.
-
Made of high-quality cast iron
-
Equipped with swivel base with 360o pitch, 1o gradation
-
Body, along with the moving jaw, is made of high-quality cast iron
-
Top side of the lead screw secured from dirt and chips
-
Possible disassembly of the swivel base
-
While replacing inserts it is advised to machine their surfaces attached to the vice in order to achieve the accuracy parameters specified in the technical documentation
Technical parameters
Jaw width | 80 mm |
Height of jaw blocks | 30 mm |
Jaw spacing | 68 mm |
Swivel base | 360 ° |
Clamp key width | 14 mm |
Bolt end width | 14 mm |
Bolt | M10 |
Angular scale | 2 ° |
Dimensions | 214x115x91 mm |
Weight | 6 kg |
S | a m | h | H 1 | H | A | L | L 1 | D |
80 [mm] |
68 [mm] |
30 [mm] |
68 [mm] |
92 [mm] |
110 [mm] |
223 [mm] |
194 [mm] |
12 [mm] |
