WK80A Box-Column Drilling Machine

An industrial box-column drilling machine used for drilling, spot drilling, tapping, etc. This series of drilling machines features extreme accuracy, a broad range of speed, simple maintenance and use.

Have questions? Call us!

+48 25 631 00 27 ext.130

export@cormak.pl

Are you a member of the VIES group?

Yes - show prices with VAT 0%

VAT included

€19,975.00

The lowest price of this product in the last 30 days before the discount was €19,455.65 gross

There are not enough products in stock

I agree to the terms and conditions and the privacy policy

Instructions in Polish
Service
Warranty 12/24 months
Delivery
Free

Machine features

An industrial box-column drilling machine used for drilling, spot drilling, tapping, etc. This series of drilling machines features accuracy, low noise levels, a broad range of speed, centralised control panel as well as simple maintenance and use.

Quick and easy feed and speed adjustment, due to a convenient lever
High power and torque motor
Tapping through automatic rotation change and depth adjustment
Spindle autofeed, tapping capability and lighting in default equipment
Rapid feed and return motor
Trouble-free and long-term reliability due to high-quality parts and components
Sturdy and solid column and base

Technical data

Maximum drilling diameter	80 mm
Tapping	M56
Torque	800 Nm
Column head movement	260 mm
Morse taper	MK6
Spindle speed (9 gears)	40–570 rpm
Feed range	(6) 0.1–0.78 mm / turn
Feed force	30000 N
Gap from arbor to column	375 mm
Maximum gap from arbor to table	870 mm
Spindle stroke	250 mm
Table/T-slots	660×555 mm / 22 mm
Table travel	300 mm
Motor power	5.5 kW
Machine dimensions	900×1300×2850 mm
Weight	2500 kg
