W16 Bench Drilling Machine
Universal drilling machine for drilling, reaming, tapping. Equipped with a tilt table, rotary and self tightening chuck. 125 mm vice included in the set.
Variant
WS32 Bench Drilling Machine
WS16 Bench Drilling Machine
WS20 Bench Drilling Machine
Z7016 Vario Bench Drilling Machine
WS20B Bench Drilling Machine with Autofeed
W25 Bench Drilling Machine
CORMAK WS32BC table drill with auto feed
Z7020 Vario metal bench drill
Are you a member of the VIES group?
VAT included
€974.75
The lowest price of this product in the last 30 days before the discount was €949.41 gross
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
Free
Machine description
- Tapping function
- Automatic spindle rotation direction during tapping
- Manual rotation direction change with a hand lever
- High spindle rigidity
- Capability of setting required drilling/tapping depth
- Power transmitted through a belt drive
- Worktable with adjustable height, from -45 to +45 degrees swivelling, with 360 degrees rotation around column
- Base equipped with 14 mm wide T-slots
- Belt drive guard equipped with limit safety switch
Technical data
| Maximum drilling depth | 16 mm |
| Maximum spindle quill extension | 100 mm |
| Spindle taper | MK2 |
| Spindle speed | 480, 800, 1400, 2440, 4100 rpm |
| Spindle axis from column distance | 193 mm |
| Table dimensions | 200x230 mm |
| Base dimensions | 528x360 mm |
| Maximum spindle tip from table distance | 315 mm |
| Maximum spindle tip from base distance | 556 mm |
| Worktable horizontal axis rotation range | ±45° |
| Worktable vertical axis rotation range | 360° |
| Motor power | 750 W/400V |
| Weight | 90 kg |
In the set
- 125 mm vice
- B18 self-tightening drilling chuck
- MK2 drilling chuck mandrel
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
