Automatic, column-type metal band saw CORMAK HR-500SA

The CORMAK H-500SA column band saw is a high-performance machine for automatic cutting of solid elements and profiles. The solid body and strong saw frame combined with the column construction provide excellent rigidity and an exceptional level of stability during the cutting process of even the most difficult metals. The cutting machine is equipped with a PLC controller and an easy-to-use touch screen. An undoubted advantage of this model is the swivel head, which allows cutting in the range of 0°- 60° - in automatic and semi-automatic cycles - smooth angle adjustment.

Variant

S-200RHA Automatic Band Saw

C33 Automatic Column Band Saw

Automatic column band saw CORMAK H-260SA

Automatic column band saw CORMAK H-280SA

Automatic column band saw CORMAK H-300SA

CORMAK H-400SA automatic column band saw for metal

CORMAK H-500SA automatic column band saw for metal

CORMAK HR-350SA automatic column band saw for metal

Automatic, column-type metal band saw CORMAK HR-600SA

Have questions? Call us!

+48 25 631 00 27 ext.105

export@cormak.pl

Are you a member of the VIES group?

Yes - show prices with VAT 0%

VAT included

€28,875.00

The lowest price of this product in the last 30 days before the discount was €28,124.25 gross

access_time Shipping time: 7 working days after receipt of payment

Instructions in Polish
Service
Warranty 12/24 months
Delivery
Free

Manual and Automatic Mode : The cutting machine allows both manual operations from the machine's control panel in manual mode and automatic cutting cycle in automatic mode, eliminating the need for constant operator service.
Upper vice pressure: The cutting machine is adapted to batch cutting .
Automatic Cutting Cycle : In automatic mode, the entire cutting process, including securing the part, moving it to a specified dimension, lowering the cutting arm and lifting it after cutting is completed, takes place without the operator's participation.
Panel Controlled Parameters: Cutting parameters, such as the number of pieces, dimensions of parts, belt speed, and others, are set and controlled using a control panel with an easy-to-use touch screen.
Solid Construction: The machine body is made of cast iron mounted on a rigid, spatial plate construction of the housing, providing exceptional rigidity and stability.
Cutting Band Drive : A powerful three-speed motor, hydraulic belt tension, and a cooling system and cleaning brush contribute to precise and efficient cutting.
Safety System : In the event of a cutting band break, the machine stops automatically, which increases the safety of the operator.
Hydraulic Material Feed System: This system allows a fully automatic machine work cycle, with precise adjustment of the material feed length.
Innovation and ISO Standards: Cormak provides innovative solutions and production in accordance with ISO:90001 and ISO:140001 standards, which proves high quality, safety and product reliability.

Technical data:

Cutting range	Ø500 or 650 x 550
Tape	6600 x 41 x 1.3 mm
Cutting speeds	27/45/69 m/min.
Total power	6.5kW
Tape tensioning	Manual
Feeder stroke	500mm
Table height	715mm
Dimensions	3200x3050x2115mm
Libra	3200kg
