WK25 Box-Column Drilling Machine
An industrial box-column drilling machine used for drilling, spot drilling, tapping, etc. This series of drilling machines features extreme accuracy, a broad range of speed, simple maintenance and use.
Are you a member of the VIES group?
VAT included
€4,975.00
The lowest price of this product in the last 30 days before the discount was €4,975.00 gross
-
- Instructions in Polish
- Service
- Warranty 12/24 months
-
Delivery
250,00 PLN
Machine features
An industrial box-column drilling machine used for drilling, spot drilling, tapping, etc. This series of drilling machines features extreme accuracy, a broad range of speed, simple maintenance and use.
- Quick and easy feed and speed adjustment, due to a convenient lever
- High power and torque motor
- Tapping through automatic rotation change and depth adjustment
- Spindle autofeed, tapping capability and lighting in default equipment
- Rapid feed and return motor
- Trouble-free and long-term reliability due to high-quality parts and components
- Sturdy and solid column and base
- Optional choices: 160×125 mm or 495×165 mm cross table
Technical data
|
Maximum drilling diameter |
25 mm |
|
Tapping |
M16 |
|
Torque |
160 Nm |
|
Column head movement |
200 mm |
|
Morse taper |
MK4 |
|
Spindle speed (6 gears) |
82, 142, 260, 415, 716, 1300 rpm |
|
Feed range |
0.10, 0.15, 0.25 mm / turn |
|
Gap from arbor to table |
280 mm |
|
Maximum gap from arbor to table |
700 mm |
|
Spindle stroke |
200 mm |
|
Table/T-slots |
560×410 mm / 14 mm |
|
Table travel |
300 mm |
|
Motor power |
2.2 kW |
|
Machine dimensions |
1050×680×2010 mm |
|
Weight |
1000 kg |
Manufacturer: Cormak
CORMAK JERZY ZALEWSKI
street Brzeska 120, 08-110 Siedlce, Poland
